REV 1 CT-3500 S2 USER’S MANUAL
15
3.5.2. Timing an OPEN Operation
Follow the steps below to time an OPEN operation:
a. Start from the “START-UP” menu:
Press the [1] key (TIME BRKR).
b. The following screen will be displayed:
Press the
[1]
key (OPEN).
c. The following screen will be displayed:
Manually open the breaker.
d. The following screen will be displayed:
Press the [1] key (YES) to print the test results on the unit’s built-in thermal printer.
PRINT TEST RESULTS?
1.YES
2.NO
TEST: OPEN
OPEN BREAKER NOW...
TIMING MODE:
1.OPEN 2.CLOSE
3.OPEN-CL 4.CL-OPEN
5. SP OPEN
1. TIME BRKR 05/14/12
2. GET RSLT 08:45:25
3. SETUP
4. DIAGNOSTICS
