REV 1 ATRT-01/01B S3 USER’S MANUAL

d. The following screen will be displayed:

Select the transformer configuration by pressing the corresponding key (

[1]

[6]

). For

this example, press the

[1]

key (Dy1).

e. The following screen will be displayed:

NOTE

Option 3 (USE PREV DATA) will be listed only if you had provided name plate
voltages for a previous test.

1. YES

Press the

[1]

key (YES) if you would like to enter the transformer name plate

voltage values. The following screen will be displayed:

Type the H winding name plate voltage value using the numeric keypad. The
screen will be updated as shown:

Press the

[ENTER]

key. The following screen will be displayed:

NAME PLATE VOLTAGE:

H : X

500 :

NAME PLATE VOLTAGE:

H : X

0 :

NAME PLATE VOLTAGE?
1. yes
2. no
3. USE PREV DATA

1. DY1
2. DY3
3. DY5
4. DY7
5. DY9
6. DY11
