TREND IQView.._RPM - Manual (Page 9)

9 IQView../RPM Installation Instructions TG200712 Issue 1/F 10/01/07
Installation Instructions IQView../RPM
Test System
13
(a) Tap on controller icon in navigator e.g. (IQ2 controller)
(b) Tap on controller menu icon e.g.
(c) Tap on ‘Modules’/’Sensors’ on drop down menus
(d) Check sensors display
3.2 Installation - Configuration
(continued)
Test Relay Output 14
(a) Tap in the menu rail on top of the screen and tap on
‘Settings’/’Alarms’
(b) Tap on the relay action (to select relay action)
(c) Tap to close the box
(d) Tap in bottom rail of screen
(e) Tap and choose ‘Turn alarm on’ from drop down menu
(f) Listen for relay to click and check relay operates the connected device
(g) Tap in bottom rail of screen to stop alarm test.
if required
