8 IQView../RPM Installation Instructions TG200712 Issue 1/F 10/01/07
IQView../RPM Installation Instructions
7 6 5 4
R+ R- T+ T-
O
I
IQView
?
IQView
?
3 2 1
1
LINK
RS232 Rx Tx
OK
28-36 V
24 V ETHERNET
OK
DATA R+ R- T+ T-
7 6 5 4
7 6 5 4
R+ R- T+ T-
IQView
3.2 Installation - Configuration
(continued)
Open Panel
9
if ‘Connect to CNC’/’Ethernet (vCNC)’,
‘Connect as Device’/’Ethernet Lan’, or
‘Connect as Device’/’Current Loop Lan’
Check Ethernet OK LED
10
Check Current Loop Lan LEDs
11
if ‘Connect as Device’/’Current Loop Lan’
3 2 1
1
LINK
RS232 Rx Tx
OK
28-36 V
24 V ETHERNET
OK
DATA R+ R- T+ T-
7 6 5 4
IQView Faulty
Check network cabling for
short circuits with a
multimeter (NOT Megger)
Check baud rate. Power
up other nodes until faulty
node is found (OK ).
Correct fault.
Network Address Invalid
0,2,3 or >119
OK
OK
(green)
(yellow)
(yellow)
Ethernet OK
(green)
Check Ethernet Connection
and/or vCNC
RX
TX
OK
a
b
c
rear view
of connector
rear view
of connector
Close Panel
12
if appropriate
