Specification
PowerRail303 Page 14
6 Specification
Aux Mains Nominal 230Vac ±15%, 45-65Hz, 1W max.
Optional 115Vac ±15%.
Input Voltage Un 400V Line-Line. Range 20%-120% Un
Burden 0.1VA / Phase. Overload 2xUn
Continuous.
Other nominal voltages are available to order.
Input Currents Nominal Ib = 5A. Range 0.2%-120% Ib
Burden 0.1VA / Phase. Overload 20xIb (1 sec)
Isolation 2.5kV (1 minute)
Optional Ib = 1A
Accuracy KWh: Class 1.
EN62053-21 & BS8431 (2% - 120% Nominal
Load)
KW: 1% Rdg (5% - 120% Nominal Load)
LCD Display Green Backlit LCD 8 Digits h=9mm + Legends.
kWh Memory 10 years without power.
Pulse Output Normally open volt free contacts
1 pulse per energy increment.
Pulse rate and length selectable.
Contacts: 100V ac/dc, 100mA, 5W max
Isolation 2.5kV for 1 minute.
Environment Operate -10C > T < 65C. RH < 75% Non
Condensing
Storage -25C > T < 75C
Other Size: 106 x 90 x 58mm
Cut out: 106 x 45mm
Case:
Noryl UL94 V-0 Self Extinguishing
Terminals: Rising Cage 4.0mm
2
Weight: Approx 250g
