TREND T_PI User Manual
Page 6
T/PI
Installation Instructions
T/PI PRT Insertion Temperature Sensor Installation Instructions TG200825 Issue 1/C 25/06/07
6
Installation
(continued)
Configure IQ
11
I Q
IQ Configuration
Manual 90-1533
I Q
or
Replace Lid
10
Note that IP67 (NEMA6) rating is only
achieved if the sensor is correctly installed
with cable or conduit connection fully
tightened.
Replace Connector
9
