T/PI PRT Insertion Temperature Sensor Installation Instructions TG200825 Issue 1/C 25/06/07 3
Installation Instructions T/PI
Install Immersion Sensor 3
a2
a3
(if installing new pocket)
b Install Sensor into Pocket
a
Drill hole for boss Fix threaded boss
*Screw pocket into boss
½” BSPT
threaded boss
If using compatible pocket
use 2 mm hexagonal socket key
tighten screws
Install Pocket
a1
Installation (continued)
c1
If using Universal Fixing Kit
Push adaptor onto probe Adjust probe length
*Mount in pocket
if pocket has grub screw, discard spring and clip
clip
spring
brass brush
tighten
use 2 mm
hexagonal socket key
pocket
length
clip engages
in groove
probe is forced
against end of
pocket
tighten screw
over bush
c Install Sensor into Pocket
c3
c2
if pocket has clip retaining groove, push
clip over pocket
*If used for chilled water ensure pocket is sealed around probe or fill pocket with thermally
conducting oil to avoid the build up of condensation in bottom of pocket.
apply sealent to
boss thread use M27 Spanner
