Required Test Equipment
The following table lists the test equipment and accessories, or their equivalents, required for
performance verification of the WaveLink Medium Bandwidth Differential Probes.
Because the input and output connector types may vary on different brands and models of test
instruments, additional adapters or cables may be required.
Test Equipment
Minimum Requirements
Example Equipment
Oscilloscope
Instrument bandwidth ≥ probe
warranted bandwidth
ProLink input
Teledyne LeCroy
WaveMaster 8 Zi/Zi-A
Digital Multimeter
AC: 0.2% accuracy to measure
200 mV and 2 Vrms @ 1 kHz
6½ digit resolution
Agilent Technologies 34401A
Fluke 8842A-09
Keithley 2001
Oscillator/
Function Generator
Sine Wave output, adjustable
from 500 mV to 4 Vp-p (357 mV
to 2.83 Vrms) at 70 Hz
Stanford Research DS340
Agilent Technologies 33120A
Leader LAG-120B
Calibration Fixture *
Teledyne LeCroy PCF200
ProLink Adapter
Teledyne LeCroy LPA-2.92
or LPA-SMA
SMA to BNC Adapter
Pomona Electronics 4289
Pasternack Enterprises PE9073
SMA Coaxial Cable
Pomona Electronics 4846-K-24
Pasternack Enterprises PE3369-36
* Standard accessory included with WL-PLINK-CASE.
