Operator's Manual
Complete Probe System (-PS)
By design, the WaveLink probes are modular in nature. However, to make selection easy, a complete
probe system is available for purchase. These all-inclusive probe systems contain the following
items:
l
Platform/cable assembly kit
l
Amplifier system (with solder-in interconnect leads and square pin lead)
l
Positioner tip kit
Just choose the appropriate bandwidth (8, 10, or 13 GHz) for the probe system.
NOTE: The 13 GHz probe system browser is rated to 10 GHz . The SMA/SMP Interconnect Lead is
not part of the complete probe system but may be purchased as an accessory.
Standard Accessories Dxx30-PS
WL-PLINK-CASE Platform/Cable Assembly 1 each
Dxx30 Amplifier Module with Solder-in Interconnect Leads and Square Pin Lead 1 each
Dxx30-PT-KIT Positioner Tip (Browser) Kit 1 each
Dxx30-PS Complete Probe System.
924234-00 13
