ADP015 Current Probe
18 922254-00 Rev A
Results
Step Description Intermediate Data Test Result
Bandwidth:
A-8 Probe Bandwidth (> 50 MHz) ___________MHz
DC Accuracy:
B-10a 15 A Current Sense (a) ___________V
B-10b 15 A Probe Output (b) ___________V
B-11 15 A Current (c) ___________A
B-12 15 A Accuracy (< ±1%) ___________%
B-15a 30 A Current Sense (d) ___________V
B-15b 30 A Probe Output (e) ___________V
B-16 30 A Current (f) ___________A
B-17 30 A Accuracy (< ±2%) ___________%
Peak Current:
C-2 50 A DC Current (> 10 s) ___________s
