Zi Rackmount Accessory
Parts Removed from Oscilloscope for Rackmounting
WavePro 7 Zi
Part
Teledyne LeCroy Part Number
Qty. Per Unit
Bucket Backshell
915585-00
1
Cover (Left)
915693-00
1
Cover (Right)
915694-00
1
Cover (Top)
915692-00
1
Metal Wrap (Bottom)
915592-00
1
M3 X 6 Torx Screw with Washer
916083-00
8
M3 X 10 Torx Screw with Washer (Black)
916085-00
22
M3 X 10 Torx Screw with Washer
916084-00
3
Socket Head Cap Screw M4 X 12
42A0000000735
4
WaveMaster 8 Zi
Description
Teledyne LeCroy Part Number
Qty. Per Unit
Bucket Backshell
916238-00
1
Upper Left Cover
916239-00
1
Lower Left Cover
916240-00
1
Cover (Right)
916241-00
1
Cover (Top)
916242-00
1
Metal Wrap
916246-00
1
M3x10 Hex Cap Screw (Black)
42A0000000737
8
Flat Washer 3, 9mm, OD
42551130100
8
M3 External Tooth Washer
42A0000000738
8
M3 X 6 Torx Screw with Washer
916083-00
15
M3 X 10 Torx Screw with Washer (Black)
916085-00
15
M5x8 Torx Screw
916492-00
2
M5x12 Torx Screw
916493-00
7
NOTE: Store parts removed from the instrument in a safe place for reuse. If the unit needs to be returned
to Teledyne LeCroy, all parts should be reassembled to the oscilloscope prior to shipment.
