Steelcraft Automotive 223100 3 ROUND SIDE BAR User Manual
Page 3
3" SIDEBAR
07-14 JEEP PATRIOT
Page 3 of 5
8/15/13 REV1 (DP)
Driver Side Installation Pictured
Fig 2A
(Fig 1) Driver side front mounting location
Fig 2B
(Fig 3) Insert (1) 12mm Bolt Plate into the hole in
the bottom of the inner frame channel
12mm Bolt Plate
12mm Flat Washer
12mm Lock Washer
12mm Hex Nut
Insert (1) 12mm Bolt Plate into the inner small
oval hole and back out the larger oval hole
Driver side inner frame channel
Front
Front
Front
