Steelcraft Automotive 133150 RUNNING BOARD User Manual

Page 4

VIEWPOINT RUNNING BOARDS

2010-12 LEXUS RX350

Page 4 of 8

10/23/12 (DP)

(Fig 9) Passenger side front
mounting location pictured

Front

6mm Hex Bolt
6mm Lock Washer
6mm Flat Washer

10mm Hex Bolt
10mm Lock Washer
10mm STD Flat Washer

(Fig 6) Passenger/Right side front pictured

Fig 5

6mm Threaded Insert

Fig 7

Fig 8

6mm Threaded Insert

Front

Bolt passenger side front Bracket in
place. Mark location of slot on
bottom of frame channel to drill for
6mm Threaded Insert (see Fig 7)

10mm Threaded Insert.
Drilling may be required

NOTE: To insert a 10mm
Threaded Insert into the
large factory hole, check
for fit and/or use 1/2"
drill bit as necessary
