LevelOne FCS-1091 - Manual (Page 8)

4
Physical Details - FCS-1091/WCS-1090
Front - FCS-1091/WCS-1090
CS Mount Lens Adjust focus manually by turning the front lens clear. You also
should ensure that the lens cover remain clean. The image
quality is degraded if the lens cover is dirty or smudged.
Microphone The built-in microphone is mounted on the front. There is also
a connection for an external microphone on the rear.
Connecting an external microphone will disable the built-in
microphone.
Power LED
(Amber) On - Power on.
Off - No power.
Blinking - The Power LED will blink during start up. This will
take 15 to 20 seconds.
Network LED
(Green) On - Wireless or LAN connection is detected.
Off - Wireless or LAN connection is not detected
Blinking - Data is being transmitted or received via the LAN
or Wireless connection.
Rear - FCS-1091/WCS-1090
Antenna For WCS-1090, attach the supplied antenna here. The
antenna is adjustable; best results are usually obtained with
the antenna positioned vertically.
Reset Button This button is recessed; you need a pin or paper clip can be
used to depress it. It can be activated at any time the camera
is in the "ready" mode.
• WPS PBC Mode. For the WCS-1090, when pressed and
released (less then 3 seconds), the FCS-1091/WCS-1090
will be in the WPS PBC mode (Auto link mode).
• WPS Pin Code Mode. For the WCS-1090, when pressed
and held for over 3 seconds, the FCS-1091/WCS-1090
will be in the WPS Pin Code mode.
• Reset to manufacturer default value and reboot. When
pressed and held over 10 seconds, the settings of FCS-
1091/WCS-1090 will be set to their default values.
Note:
After this procedure is completed, the Power LED will blink
three times to confirm that the reset was completed
successfully.
