Trigger Event

Enable

Check to perform all of the event(s) that were configured and
scheduled.

Interval

Select the desired option for the events interval. (* "0" = No
Delay)

Trigger by

• Input 1 / 2 - This describes the states that the input(s)

must be in for an event to be triggered. Only one input can
be used, also note that the states for all the inputs used
must be reached before the event will be triggered.

• Motion Detection - Movement in a motion detection

window can be used to trigger events.

Actions

• E-Mail - If checked, an E-Mail (with "Attachment") will be

delivered to the SMTP server. (SMTP Server must be
configured on the E-Mail page.)

• FTP - If checked, an FTP upload will be activated to the

FTP server. (FTP servers must be configured on the FTP
page.)

• Output 1 / 2 - If checked, the output port(s) state will be

activated as configured. (Output port(s) must be
configured on the I/O Port page.)

• Instant Messaging - If checked, an Instant Messaging (IM)

will be delivered to the Jabber server. (Jabber server must
be configured on the Instant Messaging page.)

Attachment Type

• Overwrite/Replace oldest video file

Check to overwrite/replace the oldest video clip with the
current recording when detecting device's SDRAM is full.

• JPEG Image:

Frame Rate - Select the desired capture rate for the JPEG
image(s) here.
Pre/Post Capture - Select the desired length. The
snapshot(s) of the JPEG image depends on this setting,
and also the file size and degree of compression.

• Video:

Video Format - Select the desired type for the video file.
Pre/Post Capture - Select the desired length. The size of
the file depends on this setting, and also the Video size
and degree of compression.
