Commissioning
Code Possible Settings
IMPORTANT
No. Name Default Selection
P718 Segment #2
Digital Output
State
0 Bit0 Relay bit = 0: OFF (De-energized)
bit = 1: ON (Energized)
The corresponding digital output/
relay must be set to accept value the
from the sequencer: P140, P142=27
Bit1 TB14
P719 Segment #2
TB30
Analog Output
Value
0.00 0.00 {VDC} 10.00 TB30 configuration parameter must
be set to accept this value: P150
= 10
Segment #3
P720 Segment #3
Frequency
Setpoint
0.0 -500.0 {Hz} 500.0 If P112 = 1, negative sign forces
reverse direction
P721 Segment #3
Accel/Decel Time
20.0 0.0 {sec} 3600.0
P722 Segment #3
Time in current
step
0.0
0
0.0 {P708} 6553.5
0 {P708} 65535
Scaling/units depend on P708
Skip segment if time = 0
P723 Segment #3
Digital Output
State
0 Bit0 Relay bit = 0: OFF (De-energized)
bit = 1: ON (Energized)
The corresponding digital output/
relay must be set to accept value the
Bit1 TB14
P724 Segment #3
TB30
Analog Output
Value
0.00 0.00 {VDC} 10.00 TB30 configuration parameter must
be set to accept this value: P150
= 10
Segment #4
P725 Segment #4
Frequency
Setpoint
0.0 -500.0 {Hz} 500.0 If P112 = 1, negative sign forces
reverse direction
P726 Segment #4
Accel/Decel Time
20.0 0.0 {sec} 3600.0
P727 Segment #4
Time in current
step
0.0
0
0.0 {P708} 6553.5
0 {P708} 65535
Scaling/units depend on P708
Skip segment if time = 0
P728 Segment #4
Digital Output
State
0 Bit0 Relay bit = 0: OFF (De-energized)
bit = 1: ON (Energized)
The corresponding digital output/
relay must be set to accept value the
Bit1 TB14
P729 Segment #4
TB30
Analog Output
Value
0.00 0.00 {VDC} 10.00 TB30 configuration parameter must
be set to accept this value: P150
= 10
