46
Commissioning
Code Display Range
(READ ONLY)
IMPORTANT
No. Name
P512 Heatsink Temp 0 {°C} 150 Heatsink temperature
P520 0-10 VDC Input 0.0 {VDC} 10.0 Actual value of signal at TB-5
P521 4-20 mA Input 0.0 {mA} 20.0 Actual value of signal at TB-25
P522 TB-5 Feedback P204 P205 TB-5 signal value scaled to PID feedback units
P523 TB-25 Feedback P204 P205 TB-25 signal value scaled to PID feedback units
P525 Analog Output 0 {VDC} 10.0 See P150…P155
P527 Actual Output
Frequency
0 {Hz} 500.0
P528 Network Speed
Command
0 {Hz} 500.0 Command speed if (Auto: Network) is
selected as the speed source
P530 Terminal and
Protection
Status
Indicates terminal status using segments of
the LED display. (See section 4.5.7.1)
P531 Keypad Status Indicates keypad button status using segments
of the LED display. (See section 4.5.7.2)
P540 Total Run Time 0 {h} 9999999 Alternating display: xxx-; yyyy when value
exceeds 9999
P541 Total Power On
Time
0 {h} 9999999
P550 Fault History 1 8 • Displays the last 8 faults
• Format: n.xxx where: n = 1..8,
1 is the newest fault; xxx = fault message
(w/o the F.)
• Refer to section 5.3
P551 Fault History
Time
0 {h} 999999 Display: “n.hh-” “hhhh” “mm.ss” = fault #,
hours, seconds.
The “hhhh” screen is displayed after hours
exceed 999.
P552 Fault History
Counter
0 255 Number of sequential occurrences of a fault.
For example: 3 external faults occur over a
period of time with no other errors occurring.
Then P552 will indicate 3, P550 will indicate
the error EF and P551 will indicate the time of
the first fault occurrence.
P560 Sequencer:
Currently
Active Segment
0 17
P561 Sequencer: Time
since Start of
Active Segment
0.0 {P708} 6553.5
0 {P708} 65535
Unit depends on P708 (0.1sec, sec or minutes)
