LEESON SM4 Series Flux Vector - Manual (Page 27)

26
Commissioning
4.5.2 I/O Setup Parameters
Code Possible Settings
IMPORTANT
No. Name Default Selection
P113 Auto/Manual
Control
0 0 Terminal Strip Control The reference is dictated by the
settings and state of the TB-13x
terminals. If no AUTO reference has
been setup on the terminal strip then
reference control is dictated by P101.
1 Auto/Manual (CTRL button
select)
Allows the reference to be switched
between auto and manual using
the CTRL pushbutton on the drive
keypad. If the CTRL pushbutton
has selected AUTO reference but
no AUTO reference has been setup
on the terminal strip, then reference
control is dictated by P101.
2 Manual Control Only Reference is dictated by P101
regardless of any AUTO source
that may be selected by the TB-13x
terminals.
NOTE
P113 is applicable to 15 HP (11kW) and higher models only.
P115 MOP Speed
Initialization at
Power-Up
0 0 Set to last MOP speed at
power up
1 Set to 0.0Hz at power up
2 Set to Preset #3 at power up
P120 Assertion Level 2
1 Low
P120 and the Assertion Level
switch must both match the desired
assertion level unless P100, P121…
P123 are all set to 0. Otherwise an
F.AL fault will occur.
2 High
