LEESON SM4 Series Flux Vector - Manual (Page 50)

49
Commissioning
Code Possible Settings
IMPORTANT
No. Name Default Selection
P626 Network Timeout
Action
4 0 No action Modbus
1 Stop (P111)
2 Quick Stop
3 Controller Inhibit
4 Trip Fault, F.nF1
0 0 No action Lecom
1 Controller Inhibit
2 Quick Stop
3 Trip Fault, F.nF1
P627 Network Messages
Received
Read-Only: 0 - 9999 Valid network messages received
NOTE: When the number of messages exceeds 9999, the counter resets
and resumes counting from 0.
4.5.9 Sequencer Parameters
The P700 sequencer parameters are listed herein. Refer to section 4.5.7 for P56x Sequencer Diagnostic
Parameters.
Code Possible Settings
IMPORTANT
No. Name Default Selection
P700 Sequencer
Mode
0 0 Disabled If P700 = 0 and no reference (P121,
P101) points to any of the sequence
segments, then P701-P799 will not
be displayed on the local keypad.
1 Enabled: transition on timer only
2 Enabled: transition on rising
edge (P121, 122, 123 = 25 step
sequence)
3 Enabled: transition on timer or
rising edge
P701 Sequencer:
TB13A Trigger
Segment
1 1 - 16
TB13A = lowest priority
Asserting TB13A with selection
#24 (Start Sequence), starts the
sequence operation from the
segment specified in this parameter.
P702 Sequencer:
TB13B
Trigger Segment
1 1 - 16
TB13B: higher priority than TB13A
Asserting TB13B with selection
#24 (Start Sequence), starts the
sequence operation from the
segment specified in this parameter.
P703 Sequencer:
TB13C
Trigger Segment
1 1 - 16
TB13C: higher priority thanTB13B, A
Asserting TB13C with selection
#24 (Start Sequence), starts the
sequence operation from the
segment specified in this parameter.
P704 (2) Sequencer:
TB13D
Trigger Segment
1 1 - 16
TB13D: higher priority than TB13C,
B, A
Asserting TB13D with selection
#24 (Start Sequence), starts the
sequence operation from the
segment specified in this parameter.
(2) Parameter applicable to models 15HP (11kW) and higher.
