KB Electronics KBMA-24DF User Manual
Page 9
9
Description
Specification
Factory Setting
115 Volt AC Line Input Voltage Operating Range (Volts AC)
1
115 (±15%)
—
208/230 Volt AC Line Input Voltage Operating Range (Volts AC)
1
208 (-15%) / 230 (+15%)
2
—
Maximum Load (% Current Overload for 1 Minute)
150
—
Horsepower Selection (HP) (J2)
1/8, 1/4, 1/2, 3/4, 1
1
Carrier, Switching Frequency (kHz)
16, 8
—
Output Frequency Resolution (Bits, Hz)
10, .06
—
Minimum Speed Trimpot (MIN) Range (% Frequency Setting)
0 – 40
0
Maximum Speed Trimpot (MAX) Range (% Frequency Setting)
70 – 110
100
Acceleration Trimpot (ACCEL) and Deceleration Trimpot (DECEL) Range (Seconds)
.3 – 20
1.5
Slip Compensation Trimpot (COMP) Range at Drive Rating (Volts/Hz)
0 – 3
1.5
Current Limit Trimpot (CL) Range (% Full Load)
40 – 200
160
Motor Frequency Setting (Hz) (Jumper J5)
50, 60
60
Output Frequency Multiplier (1X, 2X) (Jumper J4)
3
1, 2
1
Minimum Operating Frequency at Motor (Hz)
0.3
—
Speed Range (Ratio)
60:1
—
Speed Regulation (30:1 Speed Range, 0 – Full Load) (% Base Speed)
4
2.5
—
Overload Protector Trip Time for Stalled Motor (Seconds)
6
—
Undervoltage/Overvoltage Trip Points for 115 Volt AC Line Input (±5%) (Volts AC)
1
76 – 141
—
Undervoltage/Overvoltage Trip Points for 208/230 Volt AC Line Input (±5%) (Volts AC)
1
151 – 282
—
Run/Fault Relay Output Contact Rating (Amps at 30 Volts DC, 125 Volts AC, 250 Volts AC)
1, 0.5, 0.25
—
Operating Temperature Range (°C / °F)
0 – 45 / 32 – 113
—
Notes: 1. Do not operate the drive outside the specified AC line input voltage operating range. 2. The drive is factory set for 208/230 Volt AC line input
(Jumper J1 not installed). For 115 Volt AC line input, install Jumper J1 (supplied). See Figure 9, on page 16. 3. Allows the motor to operate up to two times
the rated RPM. Constant motor horsepower will result when operating the drive in the “2X” mode above the motor nameplate rated RPM. 4. Dependent on
motor performance.
TABLE 2 – GENERAL PERFORMANCE SPECIFICATIONS
Model
Part
No.
AC Line Input
Fuse or Circuit
Breaker Rating
(Amps)
Output
Net Weight
Volts AC
(50/60 Hz)
Phase
(φ)
Maximum
Current
(Amps AC)
Voltage
Range
(Volts AC)
Maximum Continuous
Load Current
(RMS Amps/Phase)
Maximum
Horsepower
(HP (kW))
Lbs.
kg
KBMA-24D
9533
115
1
16
20
0 – 230
3.6
1 (.75)
2.42
1.09
208/230
1
1
10
15
KBMA-24DF
2
9534
115
1
16
20
0 – 230
3.6
1 (.75)
2.48
1.12
208/230
1
1
10
15
TABLE 3 – ELECTRICAL RATINGS
Notes: 1. The drive is factory set for 208/230 Volt AC line input (J1 not installed). For 115 volt AC line input, install Jumper J1 (supplied). See Figure 9, on
page 16. 2. Model KBMA-24DF contains a built-in AC line Class A RFI (EMI) filter which meets the CE Council Directive 89/336/EEC Industrial Requirement.
