3.5 TRIMPOT ADJUSTMENTS (See Section 11, on pages 21 – 23.)
• Minimum Speed (MIN)
• Maximum Speed (MAX)
• Acceleration (ACCEL)
• Deceleration (DECEL)
• Slip Compensation (COMP)
• Current Limit (CL)
8
Description Part No.
Forward-Stop-Reverse Switch: Provides motor reversing, stop, and manual start functions. 9519
KBRF-300: Panel mount. AC line Class B RFI (EMI) filter which meets the CE Council Directive 89/336/EEC Residential
Requirement. Installs externally to the drive.
9484
Programming Kit: Includes DownLoad Module™ (DLM) handheld programming device which uploads and downloads
drive programs, PC to DLM serial communication cable, PC to DLM serial and USB communication cables, DLM to drive
communication cable, and PC Windows® based Drive-Link™ communication software. Available for OEM applications
only – contact our Sales Department.
9582
TABLE 1 – OPTIONAL ACCESSORIES
