Remote configuration from host user interface: synoptic table showing the output variation with
respect to the serial output configuration
Outputs
Function Mode
Analog Switching Serial
Enable - - Comm. Enable
SW
Disable - - Comm. Disable
pin5 RX connector
on 24Vdc
- - Comm. Enable
Serial
Communication
Enable
HW
pin5 RX connector
floating
- - Comm. Disable
ASCII - - Type ASCII Serial Transmission
Type Binary - - Type Binary
9600 - - -
19200 - - -
38400 - - -
Baud Rate
57600 - - -
Cyclical - -
Send every
cycle
Output changes state - -
Send when
PNP/NPN
output changes
state
Analogue output changes
state
- -
Send when
Analogue
output changes
state
Data Sending Type
On request - -
Send by host
request
Short Protocol Binary only - -
Send with
short protocol
Short Protocol enables the transmission of one single char in binary code related to one single
measure. This protocol is available in remote configuration mode only, binary transmission.
• Detection analysis and output mode: allows to set the object detection mode (normal or Teach-in),
the normally open or normally closed switching output and any delay after detection. In the latter a
delay time ranging from 0 to 200 milliseconds can be selected.
