Troubleshooting diagram 1 – IDEC MicroSmart Pentra User Manual
Page 135
W
EB
S
ERVER
CPU M
ODULE
U
SER
’
S
M
ANUAL
FC9Y-B1278
13-9
13: T
ROUBLESHOOTING
Troubleshooting Diagram 1
Is power supplied?
Is the power voltage correct?
The PWR LED does not go on.
Is the PWR LED on?
Supply power.
Is the PWR LED on?
Supply the rated voltage.
All-in-one type: 100-240V AC
24V DC
Slim type:
24V DC
Call IDEC for assistance.
END
NO
NO
NO
NO
YES
YES
YES
YES
