16
3.1.7 Attaching the Hangar Bracket and Hangar.
For MCR1000 and MCR3000 Trolleys
1) Refer to Figure 3-7 .
2) Attach the Hangar Bracket to the Side Plate with the hardware provided.
3) Attach the Hangar to the Hangar Bracket with the hardware provided.
4) Attach the Hangar to the hoist with the hardware provided.
For MCR6000 Trolley
1) Refer to Figure 3-7 .
5) Attach the Hangar to the hoist with the hardware provided.
2) Slide the Hangar Bracket through hole in Side Plate S (counterweight side), through the Hangar
and into the hole in Side Plate G.
3) Slide the Split Pin provided into the hole in the hangar on the (outside of Side Plate G).
4) Bend the Split Pin appropriately.
