9
2.2 Dimensions
Figure 2-1 Hoist Dimensions (See Table 2-2 )
Table 2-2 Hoist Dimensions
Hoist Code
Minimum
Headroom:
C
(in)
L*
(ft)
a
(in)
b
(in)
d
(in)
e
(in)
g
(in)
h
(in)
i
(in)
SNER003S 13.8 7.2
22.2 13.0 10.4 11.9
0.9
4.0 3.9
SNER005L 14.0 7.2
SNER005S 14.6 7.2
23.2 13.8 10.8 12.6 4.7 4.1
SNER010L 16.1 7.2
1.2
SNER010S 17.3 7.2
26.9 16.5 12.6 14.4
6.1 5.2
SNER020L 22.6 7.2 1.5
SNER030C 29.5 8.2 1.7 8.2 3.0
* The "L" dimensions are based on the standard lift of 10 feet.
