3 hook parts – Harrington Hoists and Cranes SNER Hoist User Manual
Page 55
Figure
No.
Part Name
Parts Per
Hoist
003S 005L 005S 010L 010S 020L 030C
1
Suspender T (for SMR Motorized Trolley)
1
ER1BS9031
ER1CS9031
ER1DS9031
ER1DL9031
ER1DR9031
2
Suspender G (for Motorized Trolley)
1
MR1DS9001
MR1ES9001
MR1FS9001
Suspender E (for Geared Trolley)
1
T7GB004010
T7GB004020 T7GB004030
Suspender E (for Push Trolley)
1
T7GB004005
T7GB004010
T7GB004020 T7GB004030
3
Connection Yoke
1
ER1BS9029
ER1CS9029
ER1DS9029
ER1DL9029
ER1DR9030
4
Connection Yoke Rubber
1
ER1BS9028
ER1DL9028
5
Yoke Bolt
1
ER1CS9032
ER1ES9032
6
Slotted Nut
1
L3183008
ES088020L
7
Split Pin
1
90094145
9009436
8
Top Hook Assembly
1
ER1BS1001
ER1BL1001
ER1CS1001
ER1CL1001
ER1DS1001
ER1DL1001
ER1DR1001
9
Hook Latch Assembly
1
ER1BS1002
ER1DS1002
ER1ES1002
ER1FS1002
10
Chain Pin
1
ES041030
11
Slotted Nut
1
M2049020
12
Split Pin
1
9009413
13
Connection Shaft
1
ER1BS9121
ER1CS9121
ER1DS9121
14
O Ring
2
9013306
9013309
9013313
15
Plate A
1
ER1BS9123
ER1DS9123
16
Machine Screw with Spring Washer
2
M6F554010
18
Fixing Shaft Assembly
1
ER1BS1122
ER1CS1122
ER1DS1122
19
O Ring
2
9013305
9013307
20 Shaft
Plug
1
ER1BS9128
ER1CS9128
ER1DS9128
22 Machine
Screw
1
9798543
10.3 Hook Parts
55
