Harrington Hoists and Cranes SNER Hoist User Manual

Page 10

background image

10

Table 2-3

Hook Dimension*

T = Top Hook

B = Bottom Hook

Units = inch

Capacity

Code

Hook

a b c d e g

003S, 005L, 005S

T

1.1

0.7

0.9

0.7

1.4

1.1

B

1.1

0.7

0.9

0.7

1.4

0.9

010L, 010S

T & B

1.4

0.9

1.2

0.9

1.7

1.2

020L

T & B

1.9

1.1

1.6

1.1

2.0

1.5

030C

T & B

2.2

1.4

1.9

1.4

2.4

1.7

*Refer to

Section 5.7

for inspection dimensions and limits.
