2 gearing parts – Harrington Hoists and Cranes SNER Hoist User Manual
Page 53
Figure
No.
Part Name
Parts Per
Hoist
003S 005L 005S 010L 010S 020L 030C
1
Bearing Holder
1
ER1CS9110
ER1DS9110
2 Socket
Bolt
3
90912133 9091220
3 Snap
Ring
1
9047262
9047262
9047275
4 Collar
B
1
ER1BS9111
5 Pinion
Assembly
1
ER1BS5220
ER1CS5220
ER1DS5220
6 Oil
Seal
1
ES221003
ES221010S
7 Ball
Bearing
1
9000507
9000509
9000609
8 Load
Sheave
1 ER1BS9241 ER1BL9241 ER1CS9241 ER1CL9241 ER1DS9241
ER1DL9241
9 Oil
Seal
1
ES232005S
ER1DS9244
10 Ball
Bearing
1
9000107
9000109
11 Snap
Ring
1
9047262
9047275
12 Load
Gear
1
ER1BL9240
ER1CS9240
ER1DS9240 ER1DE9240
13 Snap
Ring
1
9047130
9047135
9047145
14 Ball
Bearing
1
9000201
9000301
9000303
15 Ball
Bearing
1
9000301
9000204
9000404
16
Friction Clutch Set
1
ER1BB1223
ER1BC1223
ER1CB1223
ER1CC1223
ER1DB1223
ER1DC1223
ER1DE1223
17 Wavy
Washer
1
ER1BS9234
ER1CS9234
ER1DS9234
18 Oil
Seal
1
ES221005S
E6F235003S
ER1DS9233
19 Friction
Plug
1
ER1BS9235
ER1CS9235
ER1DS9235
20 Nameplate
FP
1
ER1BS9892
21 Set
Pin
S
2
ES120003
ES120010S
22 Gear
Plate
1
ER1BC9261 ER1CL9261 ER1DL9261
23 Spring
Washer
3
9012709 9012711
24
Socket Bolt
3
90912138
9091275
25
Ball Bearing
(Needle Bearing for 005L)
2
ER1BC9265
9000100
9000201
26
Gear B Assembly
1
ER1BC5262
ER1CL5262 ER1CC5262 ER1DL5262
ER1DC5262
27
Thrust Needle Bearing
1
ER1BC9268
28 Thrust
Plate
1
ER1BC9269
XX
49
10.2 Gearing Parts
53
