Fig No Part Name
Parts Per
Hoist
003S 005L 005S 010L 010S 020L 030C
1 Limit Switch Assembly
U 1 ER1BS1551
U/L 1 ER1BS2551
2 Socket Bolt 3 9091247
3 Spring Washer 3 9012709
4 Plate 1 EP1BS9441 EP1CS9441 EP1DS9441
5 Plate Screw 3 ER1BS9445
6 Hinge 1 ER1BS9442 ER1CS9442 ER1DS9442
7 Hinge Screw 2 ER1BS9443
8 Mach. Screw w/Spring Washer 2 E6F151003
9 Bushing 1 ECP99JBAA ECP99JBAB
11 Terminal Plate, 14P 1 ECP1314AA
12 Mach. Screw w/Spring Washer 2 MS555010
15 Mach. Screw w/Spring Washer 3 MS555010
16 Electromagnetic Contactor 1 MGC23306D MGC23306B
17 Mach. Screw w/Spring Washer (x) MS556010 (2) MS556010 (4)
18 Mach. Screw w/Spring Washer (x) J1AW24001010 (4) J1AW24001010 (6)
19 Starter Switch Assembly 1 EP1BS2472 EP1CS2472
19A Start Switch Only 1 9014201 9014202
20 Capacitor Assembly w/ Resistor 1 EP1BS2473 EP1CS2473 EP1BS2473
22
Transformer
- Primary = 115/230V
- Secondary = 110V
1 TRF62F601
23
Fuse
- Trans. Secondary = 110V
1 9006271
24 Mach. Screw w/Spring Washer 4 MS555010
25 Capacitor Assembly 1 EP1DS5480
10.5 Electric Parts
61
