Gilderfluke&Co 16 Bit CD-Quality Digital Audio Systems User Manual
Page 95
8
- Output 5
GREEN
Balanced Audio Line Level Negative (-) (right card #3) (26 A)
21
Ground 6
BLUE
Ground (left card #2) (28 C)
9
+ Output 6
VIOLET
Balanced Audio Line Level Positive (+) (left card #2) (27 C)
22
- Output 6
GRAY
Balanced Audio Line Level Negative (-) (left card #2) (26 C)
10
Ground 7
WHITE
Ground (right card #3) (28 A)
23
+ Output 7
BLACK
Balanced Audio Line Level Positive (+) (right card #3) (27 A)
11
- Output 7
BROWN
Balanced Audio Line Level Negative (-) (right card #3) (26 A)
24
Ground 8
RED
Ground (left card #3) (28 C)
12
+ Output 8 ORANGE Balanced Audio Line Level Positive (+) (left card #3) (27 C)
25
- Output 8
YELLOW
Balanced Audio Line Level Negative (-) (left card #3) (26 C)
13
N/C
GREEN
- Audio and AES/EBU Inputs -
- 15 Position Male DB-15 Connector -
SIGNAL NAME COLOR
SIGNAL FUNCTION
1
Ground 0
BROWN
#0 Ground (28 B)
9
+ Input 0
RED
#0 Balanced Audio Line Level Positive (+) (27 B)
2
- Input 0
ORANGE
#0 Balanced Audio Line Level Negative (-) (26 B)
10
Ground 1
YELLOW
#1 Ground (25 B)
3
+ Input 1
GREEN
#1 Balanced Audio Line Level Positive (+) (24 B)
11
- Input 1
BLUE
#1 Balanced Audio Line Level Negative (-) (23 B)
4
Ground 2
VIOLET
#2 Ground (19 B) (22 B)
12
+ Input 2
GRAY
#2 Balanced Audio Line Level Positive (+) (21 B)
5
- Input 2
WHITE
#2 Balanced Audio Line Level Negative (-) (20 B)
13
Ground 3
BLACK
#3 Ground (18B)
6
+ Input 3
BROWN
#3 Balanced Audio Line Level Positive (+) (17 B)
14
- Input 3
RED
#3 Balanced Audio Line Level Negative (-) (16 B)
7
Ground
ORANGE
#AES/EBU Ground (15 B)
15
+ AES/EBU IN
YELLOW
#AES/EBU POSITIVE Input (14 B)
8
- AES/EBU IN
GREEN
#AES/EBU NEGATIVE Input (13 B)
- SMPTE In/Out, Status Outputs, and AES/EBU Output -
- 9 Position Male DB-9 Connector -
SIGNAL NAME
COLOR
SIGNAL FUNCTION
1
- SMPTE OUT
BROWN
SMPTE OUT Ground
6
+ SMPTE OUT
RED
SMPTE OUT SIGNAL (22 C)
2
- SMPTE IN
ORANGE
SMPTE IN Ground
7
+ SMPTE IN
YELLOW
SMPTE IN SIGNAL (23 C)
3
Status #1
GREEN
Status 1 Output (16 C)
8
Status COMMON
BLUE
Status OUT COMMON (15C)
4
- AES/EBU
VIOLET
AES/EBU NEGATIVE Output (25 A)
9
+ AES/EBU
GRAY
AES/EBU POSITIVE Output (25 C)
5
+5 v/Status #2
WHITE
Status 2 Output
36
(24 A)
G
ILDERFLUKE
& C
O
. ¥ 205 S
OUTH
F
LOWER
S
T
. ¥ B
URBANK
, C
ALIF
. 91502-2102 ¥ 818/840-9484 ¥
FAX
818/840-9485
87 of 92
36
+ 5 VDC on revison 1.0 card cages
