7 PORT 4.6 (LED SEGMENT ÔBÕ)
8 PORT 4.7 (LED SEGMENT ÔGÕ)
9 PORT 5.0 (LED SELECT 0)
10 PORT 5.1 (LED SELECT 1)
11 PORT 5.2 (LED SELECT 2)
12 PORT 5.3 (LED SELECT 3) (not used)
13 PORT 5.4 (ÔUPÕ BUTTON)
14 PORT 5.5 (ÔDOWNÕ BUTTON)
15 PORT 5.6 (ÔSELECTÕ BUTTON)
16 PORT 5.7 (ÔMANUALÕ BUTTON)
17 LEFT VU LED +
18 RIGHT VU LED +
19 Vcc
20 Ground
- InfraRed Transmitter -
- 6 position RJ-11 ÔTelephoneÕ Connector -
NAME COLOR SIGNAL FUNCTION
LEFT Ground WHITE SIGNAL Ground
n/c BLACK no connection
n/c RED no connection
- TxD GREEN - DATA IN TO AB/DR-3000 (use DMX-512 - Input)
+ TxD YELLOW + DATA IN TO AB/DR-3000 (use DMX-512 + Input)
RIGHT Ground BLUE SIGNAL Ground
