- CC-3004 and CC-3016 Card Cage Connections -
- DMX-512 -
- 3 position Screw Terminal -
1 + DMX-512 (11 A)
2 Ground
3 - DMX-512 (11 C)
- RS-422 Serial Port -
- 6 position RJ-11 ÔTelephoneÕ Connector -
pin # COLOR SIGNAL NAME:
(left) 1 WHITE signal ground
2 BLACK - serial data OUT from AB/DR-3000 (12A)
3 RED + serial data OUT from AB/DR-3000 (12C)
4 GREEN - serial data IN to AB/DR-3000 (13C)
5 YELLOW + serial data IN to AB/DR-3000 (13A)
(right) 6 BLUE signal ground
- 1/4 J-6 Digital Input -
- 10 position Male IDS Connector -
COLOR SIGNAL FUNCTION
1 BROWN no connection on CC-3004 or CC-3016
2 RED Data Bit 7 (17 C)
3 ORANGE Data Bit 6 (18 C)
4 YELLOW Data Bit 5 (19 C)
5 GREEN Data Bit 4 (20 C)
6 BLUE Data Bit 3 (21 C)
7 VIOLET Data Bit 2 (22 C)
8 GRAY Data Bit 1 (23 C)
9 WHITE Data Bit 0 (24 C)
10 BLACK 12 TO 24 VDC Supply (14 C)
- 1/2 J6/A VCA Analog Inputs -
- 20 position Male IDS Connector -
SIGNAL NAME COLOR SIGNAL FUNCTION
1 Ground BROWN no connection on CC-3004 or CC-3016
2 + Supply RED no connection on CC-3004 or CC-3016
3 Analog Input 8 ORANGE CH. 8 (07H) Positive Analog Input (14 A)
4 Analog Ref. 8 YELLOW CH. 8 (07H) Negative Reference
5 Analog Input 7 GREEN CH. 7 (06H) Positive Analog Input (15 A)
6 Analog Ref. 7 BLUE CH. 7 (06H) Negative Reference
7 Analog Input 6 VIOLET CH. 6 (05H) Positive Analog Input (16 A)
8 Analog Ref. 6 GRAY CH. 6 (05H) Negative Reference
9 Analog Input 5 WHITE CH. 5 (04H) Positive Analog Input (17 A)
10 Analog Ref. 5 BLACK CH. 5 (04H) Negative Reference
11 Ground BROWN no connection on CC-3004 or CC-3016
12 + Supply RED no connection on CC-3004 or CC-3016
13 Analog Input 4 ORANGE CH. 4 (03H) Positive Analog Input (18 A)
