In this case the value scale being used is decimal:
-Gilderfluke & Company - Sixteen Channel Servo Controller - ver1.04 - c1999 DCM-
a) card serial address at __0 MSB E minimum maximum forced PowerOn
b) first output addressed at __0 address I scale scale output default
c) DMX Rx checksum enabled- yes 0 (0) |Y|__125__|__249__|_______|____0__|
1 (1) |Y|__125__|__249__|_______|____0__|
g) numbering system- decimal 2 (2) |Y|__125__|__249__|_______|____0__|
h) VT-52 compatible display- yes 3 (3) |Y|__125__|__249__|_______|____0__|
4 (4) |Y|__125__|__249__|_______|____0__|
i) twelve bit resolution- no 5 (5) |Y|__125__|__249__|_______|____0__|
j) address to test & adjust- _14 6 (6) |Y|__125__|__249__|_______|____0__|
k) test output- none 7 (7) |Y|__125__|__249__|_______|____0__|
e) auto EaseIn- 2 seconds 8 (8) |Y|__125__|__249__|_______|____0__|
p) set analog endpoints 9 (9) |Y|__125__|__249__|_______|____0__|
q) force Output to a value 10 (A) |Y|__125__|__249__|_______|____0__|
u) set min/max/forced using keypad 11 (B) |Y|__125__|__249__|_______|____0__|
t) set PowerOn defaults 12 (C) |Y|__125__|__249__|_______|____0__|
z) turn off servos on Zeros- all=0 13 (D) |Y|__125__|__249__|_______|____0__|
-> 14 (E) |Y|__125__|__249__|_______|____0__|
r) download configuration 15 (F) |Y|__125__|__249__|_______|____0__|
o) reload defaults
n) test & adjust next output l) test & adjust last output x) eXit
Enter Command-
