SER-DMX Configuration:

To enter the configuration mode you need to type the following.

The (address) is replaced by the HEX value set on the ADDRESS switches on
the front of the SER-DMX:

m5AA5(address)

If any other card is in configuration mode (or even if it just thinks

another card is in configuration), the SER-DMX won't be able to enter con-
figuration mode. To exit any other card from configuration type 'XN'. You
can then try entering configuration again.

To redraw the screen at any time, just press the ape key or

bar.

The SER-DMX will display the following screen when you enter con-

figuration mode. For eight bit resolution outputs, the menu will appear as
follows. In this example, Servo Pulse width (in milliseconds) values have
been selected for the numbers displayed.

If the configuration memory was write protected (by moving the

‘write protect’ jumper to the ‘write protected’ position), then as shown
below, the second line of the display will warn you that the configuration
can not be altered.

-Gilderfluke & Company - Sixteen Channel Servo Controller - ver1.04 - c1999 DCM-

All memory writes are disabled. You can not alter the current configuration.

a) card serial address at __0 MSB E minimum maximum forced PowerOn

b) first output addressed at __0 address I scale scale output default

c) DMX Rx checksum enabled- yes 0 (0) |Y|_1.000_|_2.000_|_______|___0%__|

1 (1) |Y|_1.000_|_2.000_|_______|___0%__|

g) numbering system- p-width in ms 2 (2) |Y|_1.000_|_2.000_|_______|___0%__|

h) VT-52 compatible display- yes 3 (3) |Y|_1.000_|_2.000_|_______|___0%__|

4 (4) |Y|_1.000_|_2.000_|_______|___0%__|

i) twelve bit resolution- no 5 (5) |Y|_1.000_|_2.000_|_______|___0%__|

j) address to test & adjust- _14 6 (6) |Y|_1.000_|_2.000_|_______|___0%__|

k) test output- none 7 (7) |Y|_1.000_|_2.000_|_______|___0%__|

e) auto EaseIn- 2 seconds 8 (8) |Y|_1.000_|_2.000_|_______|___0%__|

p) set analog endpoints 9 (9) |Y|_1.000_|_2.000_|_______|___0%__|

q) force Output to a value 10 (A) |Y|_1.000_|_2.000_|_______|___0%__|

u) set min/max/forced using keypad 11 (B) |Y|_1.000_|_2.000_|_______|___0%__|

t) set PowerOn defaults 12 (C) |Y|_1.000_|_2.000_|_______|___0%__|

z) turn off servos on Zeros- all=0 13 (D) |Y|_1.000_|_2.000_|_______|___0%__|

-> 14 (E) |Y|_1.000_|_2.000_|_______|___0%__|

r) download configuration 15 (F) |Y|_1.000_|_2.000_|_______|___0%__|

o) reload defaults

n) test & adjust next output l) test & adjust last output x) eXit

Enter Command-
