CCSAC43N40A10
N-Type Semiconductor Discharge Switch, Bare Die
Features:
• 4000V Peak Off-State Voltage
Package
• 5 kA Repetitive Ipk Capability
• 25KA/uS di/dt Capability
• Low On-State Voltage
• Low Trigger Current
Application Specific Operating Conditions:
•
•
•
Description:
• The CCS features the high peak
current capability and low On-state
voltage drop common to SCR
thyristors combined with high di/dt
capability.
• This semiconductor is intended to be
a solid state replacement for spark or
gas type devices commonly used in
pulse power applications. Schematic Symbol
• All bond areas are metalized with
solderable metal surfaces providing
the user with a solderable device that
may be installed using conventional
or lead free solders.
