Salamander Designs Synergy System SNC20C/B - Manual (Page 4)

Doc No. 500-980/v10.06 SNC 4/4
(300-470)
Washer
(300-540)
Connector Bolt
(P-300-320) - Leveler Foot
6x
6x
6x
(P-400-040) - Level
(400-060) - 3/16” Hex Key
1x
1x
Rear Panel Hardware - (PHK-240)
2x
8x
8x 8x
(400-070) - 1/8” Hex Key
(300-560) - Flat Nut (300-530) - ThumbNut
(300-510) - Stud
Double-Width Shelf Hardware - (PHK-510)
Parts
6 - Aluminum Posts 2 - Adjustable Shelf (SNC30 only)
1 - Top Shelf 1 - Spacer Tool
1 - Bottom Shelf 2 - Rear Panel
1 - Double Width Shelf 2 - Heavy Duty Shelf Bracket
(PHK-370)
Shelf Peg “B”- Right (PHK-380)
Shelf Peg “A” - Left
4x
4x
(300-490)
Low Head Screw
(300-610)
Rubber Tab
1x
(400-035) - Wrench
4x
(300-560) - Flat Nut
2x
(400-070) - 1/8” Hex Key
1x
(301-280)
Cap Plug
(300-265)
Post Cap
1x
1x 1x
(PHK-370)
Shelf Peg “B”- Right
SNC30 Only (PHK-380)
Shelf Peg “A” - Left
SNC30 Only
4x 4x
