Salamander Designs Synergy System SNX20C/B User Manual
Parts, 1x 4x 4x 4x

SYNERGY EXTENSION KIT
- SX20 / SX30 / SX40
WARNING:
If you are installing accessories such as doors or drawers to the base unit, read all instructions for the
accessory and install in conjunction with these instructions.
!
(300-450)
Connector Bolt
4x
(P-400-040) - Level
(400-060) - 3/16” Hex Key
1x
(400-080) - 5/32” Hex Key
1x
1x
Rear Panel Bag - PHK-240
1x
4x
4x
4x
(400-070) - 1/8” Hex Key
(300-560)
Flat Nut
(300-530)
ThumbNut
(300-510) - Stud
Rear Panel Bag
- PHK-150 (Only SX40)
Parts
4 - Aluminum Posts
Adjustable Shelf (SX20 -1) (SX30 - 2) (SX40 - 4)
1 - Top Shelf
Heavy Duty Shelf Bracket (SX40 - 2)
1 - Rear Panels
1 - Spacer Tool
(PHK-370)
Shelf Peg “B”- Right
SX20 -2x
SX30 - 4x
SX40 - 6x
(PHK-380)
Shelf Peg “A” - Left
SX20 - 2x
SX30 - 4x
SX40 - 6x
4x
4x
(300-490)
Low Head Screw
(300-610)
Rubber Tab
4x
(300-560) - Flat Nut
4x
(300-260) - Felt Pads
