Salamander Designs Synergy System 147C/B User Manual
Synergy 147, Quad assembly, Before you begin

BEFORE YOU BEGIN:
• Unpack all parts before beginning and refer to the drawing below.
• Shelf pegs and door hinges must slide into the channels of the post in the correct order.
They cannot be removed individually without disassembling the whole unit.
SYNERGY 147
Quad Assembly
Includes:
(1) Quad 10 Unit
(1) Set of Side Panels
(4) S10 Doors
!
!
Salamander Designs Ltd. 800-535-5659 • www.SalamanderDesigns.com
©2005 Salamander Designs Ltd. ® Synergy System, Patented.
Limited Warranty
For five full years Salamander Designs Ltd will repair or replace, at our option, any product defective in materials or craftsmanship. Salamander Designs Ltd. will not be responsible for any damage to or
destruction of other equipment consequential to our equipment failure. Defective product must be given Return Authorization and is to be returned to the factory prepaid, in the original carton and packing
material. Any damage incurred in a shipment not in original packaging shall be the responsibility of the owner. Warranty repairs will be returned prepaid, via UPS within the continental U.S.A. only.
Doc No. 501-025/v4.12 147 -1 of 4
Bottom Shelf (1)
Top Shelf (1)
Joint Connector Bolt 300-540 (10)
Sides (2)
Rear Panel (4)
Foot & Nut P-300-350 (10)
Aluminum Post (10)
Door (4)
Door
Hinge (8)
Washer 300-470 (10)
