Salamander Designs Synergy System SLW40C/B User Manual
Synergy wall assembly instructions, Parts

SYNERGY WALL ASSEMBLY INSTRUCTIONS
Hardware
Triple Wall Quad Wall
3/16” Hex Key
1x
1x
400-060
5/32” Hex Key
1x
1x
400-080
1/8” Hex Key
1x
1x
400-070
Joint Connector Bolt
2x
3x
300-540
Extension Stud
4x
5x
300-450
Cup Point Screw
2x
2x
300-505
Felt Pads
4x
5x
300-260
Metal Spacer Tabs
2x
3x
302-060
Flat Nuts
2x
2x
300-560
Caplugs
4x
6x
301-280
Grommet Cover
301-785
1x
1x
Salamander Designs Ltd. 800-535-5659 • www.SalamanderDesigns.com
©2005 Salamander Designs Ltd.
Doc.# 500-960 v 8.05 / 1 of 3
Limited Warranty
For five full years Salamander Designs Ltd will repair or replace, at our option, any product defective in materials or craftsmanship. Salamander Designs Ltd. will not be responsible for any damage to or destruction of other
equipment consequential to our equipment failure. Defective product must be given Return Authorization and is to be returned to the factory prepaid, in the original carton and packing material. Any damage incurred in a
shipment not in original packaging shall be the responsibility of the owner. Warranty repairs will be returned prepaid, via UPS within the continental U.S.A. only.
SALAMANDER
DESIGNS
SALAMANDER DESIGNS
Parts
Triple
Quad
37.75” Posts (A)
4x
5x
37.75” Posts w/Holes (B)
2x
2x
Top Shelf
1x
1x
Rear Panels
3x
4x
Side Panels
2x
2x
Adapter Plates
2x
2x
Before You Begin
If you have an assembled Synergy Base you must first
remove the connector bolts securing the top shelf using
the 3/16” hex key and set aside for Step 6.
