Salamander Designs Synergy System SNRC/B User Manual
Parts, Synergy twin riser - snr, Install connector studs

1x
(301-280)
Plastic Cap Plug
SYNERGY TWIN RISER
- SNR
(300-450) - Connector Studs
5x
Parts
5 - Aluminum Posts
1 - Top Shelf
2 - Rear Panels
(8.5” Risers Only.
Not available in custom sizes.)
5x
(300-260)
Felt Pads
(400-060) - 3/16” Hex Key
1x
1
Install Connector Studs
2
A.
Screw threaded studs into the ends of the
posts and tighten with hex key.
B.
Stick felt pads to underside of post, this will
prevent marring the surface of the top shelf.
(400-080) - 5/32” Hex Key
1x
®
Remove Top Bolts
If assembled, remove the 5 connector bolts
securing the top shelf. Set aside for Step 5.
3
Attach Riser Posts
Screw the posts into the base unit.
Be sure to square the post with the shelf.
Doc No. 500-770 / v7.05 / 1 of 2
