Salamander Designs Synergy System SNX20C/B - Manual (Page 4)

A
.
Insert Hardware
Combine the 1” threaded studs
with the flat nuts. Slide hardware
into rear channel
B
.
Allow studs to remain loose at
bottom of posts. Align the Spacer
Tool at the top of the post and
position top studs through the small
“Rear Panel” hole Secure the top 2
studs to the posts. Repeat this step
with the bottom studs, aligning the
Tool along the bottom of each post.
1
5
6
7
8
9
41/ 2 "
6"
8"
SPACER THE
DRAWER 9.375
"
1
8
9
6"
8"
SPACER THE
2X
2X
REAR
C
.
Placing Shelf
Place shelves from the bottom up.
Angle the shelf in between the front
post and set on top of shelf pegs
and heavy duty brackets.
1
2
3
4
5
S20 / SVDO REAR P
ANEL
www
.salamanderdesigns.com
EXTENDED REAR P
ANEL
S30 / S40
REAR P
ANEL
4
Insert Rear Hardware
5
Final Assembly
STOP
Side Panels
Before enclosing the unit with the top shelf install side
panels (if applicable).
See Side Panel Instructions
A
.
Secure Rear Panel
Secure thumb nuts to finish panel
installation.
B
.
Install Top
Insert the four connector bolts and
tighten shelf down.
