REPAIR, REPLACEMENT, OR CREDIT OF THE PURCHASE PRICE, AS
PROVIDED HEREIN, SHALL CONSTITUTE THE SOLE REMEDIES WITH
RESPECT TO DEFECTS IN THE PRODUCTS. THE CONSUMER ASSUMES
ALL RISKS AND LIABILITY FOR INCIDENTAL AND CONSEQUENTIAL
DAMAGE RESULTING FROM INSTALLATION AND USE OF THE THERMO-
STAT.
Some states do not allow the exclusion or limitation of incidental or
consequential damages, or allow limitations on how long an implied
warranty lasts, so the above limitations or exclusions may not apply
to you. This Warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
For Warranty returns, send the thermostat, shipping prepaid and proof
of date of purchase to:

Invensys Controls
Warranty Claims Department
515 S. Promenade Ave.
Corona, CA 92879-1736

In Canada:
Invensys Controls
Warranty Claims Department
3505 Laird Rd. Unit #14
Mississauga, Ontario L5L 5Y7 Canada

TWO YEAR LIMITED WARRANTY

Invensys Controls warrants to the original contractor installer, or to the
original consumer user, that each new Robertshaw thermostat will be
free from defects in materials and workmanship under normal use
and service for a period of two (2) years from the date of purchase
(the “Warranty Period”). If any Product fails within the applicable War-
ranty Period, Invensys Controls shall, at its option, repair or replace the
Product or credit the purchase price, provided the Product is returned
to Invensys Controls’ facility or designated agent within the Warranty
Period, with transportation or postage charges prepaid and proof of
the date of purchase, and the Product, upon examination by Invensys
Controls, is found not to conform to the Warranty. Cost of Product
removal, labor, or reinstallation of new Product are not covered under
this Warranty and are not the responsibility of Invensys Controls. War-
ranty on Products, parts and/or components sold, but not manufac-
tured by Invensys Controls, shall be expressly limited to the warranty
terms of the manufacturer of such products, parts and/or components.
The above warranty does not apply to: i) batteries; ii) defects or dam-
age that result from use of the Products in any manner other than
their normal and customary manner; iii) defects or damage that result
from use of the Products in any manner other than in accordance with
Invensys Controls’ recommendations and instructions; iv) defects or
damage which occur from misuse, alteration, accident, water, fire or
neglect; and/or v) defects due to abuse or damage such as burned
contacts, stripped threads, split castings, improper installation or
missing parts.
THE FOREGOING WARRANTY IS IN LIEU OF AND EXCLUDES ALL OTHER
WARRANTIES, WHETHER EXPRESS OR IMPLIED, INCLUDING THE IM-
PLIED WARRANTIES OF MERCHANTABILITY, TITLE AND FITNESS FOR A
PARTICULAR PURPOSE. IN NO EVENT SHALL INVENSYS CONTROLS BE
LIABLE TO CONSUMER, CONTRACTOR OR ANY THIRD PARTY FOR ANY
CONSEQUENTIAL, INCIDENTAL, SPECIAL, EXEMPLARY, OR PUNITIVE
DAMAGES ARISING FROM OR RELATING TO USE OF THE PRODUCT
INCLUDING, BUT NOT LIMITED TO, LOSS OF GOODWILL, LOSS OF
PROFIT OR REVENUE, AND PROPERTY DAMAGE, REGARDLESS
WHETHER SUCH LOSS OR DAMAGE IS BASED IN CONTRACT, WAR-
RANTY, TORT, NEGLIGENCE, STRICT LIABILITY, INDEMNITY, PRODUCT
LIABILITY, OR OTHERWISE AND EVEN IF INVENSYS CONTROLS HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

Lock Keypad

The keypad can be locked to disable the buttons on the front panel.
The two switches will continue to function.
To lock the keypad, press the

HOLD/RUN button for 5 seconds. The

lock icon will appear on the screen.
To unlock, press the

HOLD/RUN button for 5 seconds. The lock icon

will disappear.

TROUBLESHOOTING

Problem

Solution

Scrambled or double
display (numbers over
numbers).

Remove clear mylar sticker.

No display.

Check connections and batteries.
Press Reset once with a small pin and
hold for two seconds then reprogram.

Entire display dims.

Replace batteries.

Auto/Fan does not turn
On.

There may be as much as four minute
delay before the heat or cool system
turns on. Wait and check. (Compressor
protection delay).
Check your circuit breakers and
switches to ensure there is power to the
system.
Replace batteries.
Make sure your furnace blower door is
closed properly.
Check the position of the furnace or
Heat Pump selector switches.

Erratic display.

Press Reset once with a small pin and
hold for two seconds then reprogram.

Thermostat reads E1.

Temperature sensor defective. Replace
unit.

Thermostat reads E2.

System switch in wrong position. Move
system switch to correct position.

If you experience any other problems, contact Technical Support at:
www.invensyscontrols.com or (800) 445-8299.

Permanent Override

It is possible to set a temperature and hold it for an extended period,
such as a vacation.
• Press and release the

HOLD/RUN button. HOLD will flash on the

display.

• You can use the

UP and DOWN arrows to select a set temperature.

The set temperature will be held until canceled.

• To cancel the permanent override, press and release the

HOLD/

RUN button. The word SCHEDULE will appear on the display.

Home Today

This feature allows you to quickly and temporarily override your
program settings for a day with just one button.
• Press the

HOME TODAY button to enter the Home Today override.

When in Home Today mode, the thermostat will use the default
temperature setpoint.

• The display will show

HOME TODAY.

• The thermostat will remain in Home Today mode until the first

program of the next day.

• If the system is changed between

HEAT and COOL modes during

the Home Today Override period, the setpoint temperature will
automatically update. It will automatically change from the lowest
cool program setpoint to the highest heat program setpoint.

• Press the

HOME TODAY button to exit Home Today mode before

the schedule ending time.

HOME is no longer displayed on the

LCD screen, and the thermostat returns to the current program
settings.

• You can manually change the setpoint temperature while in

Home Today mode. Refer to the Temporary Override instructions.
Changing the set temperature while in Home Today mode will not
affect the Home Today ending time. However, the set temperature
will not change automatically with a manual or automatic change
between heating and cooling.

OPERATION
System Selector Switch

system

cool off heat auto

The System Selector switch on the front of the
thermostat determines the operating mode of the
thermostat. You may select

COOL, OFF, HEAT or

AUTO (RS3210 only).

NOTE: Anytime you install or remove the thermostat from the wall-

plate, slide the System Selector to the

OFF position to prevent

the possibility of a rapid system on-off.

Auto Changeover (RS3210 Only)

Auto changeover is the ability of the thermostat to switch automati-
cally between heating settings and cooling settings. This is useful in
spring and fall when the days are warm and the nights are cool. In
heat mode, if the room continues to warm beyond a set threshold, the
thermostat switches to the cool mode and the associated cool set-
tings. Likewise, in cooling mode, if the room continues to cool beyond
a set threshold, the thermostat switches to the heat mode and the
associated heat settings.
As the room temperature changes, the thermostat will call for heating
or cooling as needed. To prevent the heating and cooling systems from
overriding each other, an automatic changeover deadband is used.
The deadband is the number of degrees that the room temperature
can vary from the active setpoint until heating or cooling is called for.
The larger the deadband the more the room temperature will vary.

Fan Switch

fan

on

auto

The Fan switch should normally be set in the
AUTO position. The fan will be turned on along
with normal operation of your system. In a
normal gas or oil furnace, the fan will be turned

on by your furnace after its warm-up delay. For electric heat, air
conditioning, and heat pump operation, the fan will turn on with the
system. To run the fan continuously, slide the Fan switch to the

ON position.

Temporary Override

To temporarily change the current set temperature without affecting
your program, follow these steps:
• Press the

UP and DOWN arrows to change to your desired new

temperature.

• After 15 seconds the display will return to the normal run display.
At the next program change, the Temporary Override is canceled, and
the next program temperature becomes the setpoint temperature.

Once you have determined your Personal Program Schedule, you need
to use the instructions under Weekday/Weekend Programming to en-
ter or revise your program settings at a later date. BEFORE program-
ming your settings, there are several important guidelines and helpful
hints to follow.
• The program time can be set in 1 minute increments. This setting

will be the same for both

HEAT and COOL programs.

• The program temperature can be set in increments of 1ºF (1ºC).
• The heat setpoint cannot be set higher than the cool setpoint, and

the cool setpoint cannot be set lower than the heat setpoint.

• If the system selector is in

AUTO mode, the current system

operating mode (

COOL or HEAT) will be programmed.

• After 15 seconds without a button press, the thermostat will return

to Normal Display mode.

• When setting the program time, note the AM/PM indicator and

make sure the right one is displaying for the setting.

Weekday/Weekend Programming

:

To program the thermostat, start with a normal running display.
1. Select

COOL or HEAT.

2. Press the

PROG button and hold for three seconds.

3. Flashing at the top of the display will be the Weekdays or the

Weekend days. You can press the

PROG button to change

between Weekdays or Weekend days.

4. On the left side of the display, Morn will be shown. Press the

PROG DAY button to select the programs for Day, Eve, Nite and
back to Morn.

5. After selecting one of the four programs, you can press the

HOUR and MIN buttons to select the time for the program to
start.

6. Use the

UP and DOWN arrows to select the temperature for this

program.

7. Press the

PROG DAY button to move to the next program.

8. Repeat steps 4 through 7 for all four programs for weekdays

and weekend days.

9. Switch between

HEAT and COOL. Start with step 2 and repeat

steps 4 through 7 to set the four programs for weekdays and
weekend days.

• Press the

AUTO PROG button once. The word Auto will display.

• View the settings for all seven days of the week in the thermostat

display. These setting should match the table shown below.

Temperature in F° (C°)

Program

Number

Time

Heat

Cool

1 Morn

6:00 am

68°F (20°C)

78°F (26°C)

2 Day

8:00 am

60°F (16°C)

85°F (29°C)

3 Eve

4:00 pm

68°F (20°C)

78°F (26°C)

4 Nite

10:00 pm

60°F (16°C)

85°F (29°C)

Manual Programming

You can change the default thermostat settings and program your
own settings for weekdays and weekends. Before programming or
changing programs, use this Personal Program Schedule provided
here to determine which times and temperature settings will best
satisfy both your comfort and energy saving requirements. Use a
pencil so you can revise your records each time you change your
temperature settings.
Heating

Program

Weekday

Weekend

1 Morn

Time:
Temp:

Time:
Temp:

2 Day

Time:
Temp:

Time:
Temp:

3 Eve

Time:
Temp:

Time:
Temp:

4 Nite

Time:
Temp:

Time:
Temp:

Cooling

Program

Weekday

Weekend

1 Morn

Time:
Temp:

Time:
Temp:

2 Day

Time:
Temp:

Time:
Temp:

3 Eve

Time:
Temp:

Time:
Temp:

4 Nite

Time:
Temp:

Time:
Temp:

Configuration Menu Options

Item

Default

Temperature Scale F/C

F

First Stage Differential

1°F (0.5°C)

RS3210 only - Second Stage Differential

2°F (1.1°C)

Off Set

0

RS3210 only - DLY 2

20

RS3210 only - dEdb

3.0°F (1.5°C)

RS3210 only - System Type

HP

Configuration Menu Descriptions

Temperature Scale - Select Fahrenheit or Celsius.
First Stage Differential - When the room temperature approaches the
set temperature the differential is the amount of overshoot allowed
before the thermostat calls for heating/cooling.
Second Stage Differential - Used for RS3210, same as First Stage
Differential but controls a second stage system.
Offset - Use this to change ambient temperature readings up or down.
DLY2 - Used for RS3210 only, is the second stage delay time.
dEdb - Deadband for auto changeover. This setting is the number
of degrees the room temperature can move away from the active
setpoint temperature until heating or cooling is called for. The larger
the deadband the more the room temperature will vary.
HP - Used for selecting the system type on the RS3210. Select

HP for

heat pump. Select

STD1 for one stage heating non-heat pump. Select

STD2 for two stage heating non-heat pump.
Familiarize yourself with these manual settings, so you can easily
modify your settings as your comfort needs change.

Change Time or Day

When system switch is in

HEAT or COOL mode:

• Press

HOUR or MIN to change time.

• Press

DAY to change day.

PROGRAMMING

The reset button can be pressed with a paper clip to reset the thermo-
stat back to factory defaults.
Your thermostat is capable of holding up to four separate programs
for all weekdays, Monday to Friday, and four weekend programs for
Saturday and Sunday. Your thermostat is pre-programmed to meet
the guidelines recommended for energy efficiency. To view the default
temperature settings, follow these steps:

BATTERY WARNING

+

- +

-

Figure 6

When the batteries become weak, a flashing battery symbol will
appear on the screen. When this symbol occurs, install two new AA
batteries. You have approximately one minute to change the batteries
and keep the thermostat’s program settings. Once the batteries have
become too weak to ensure proper operation, your system will be
turned off, and the display will be blank if battery powered.
CAUTION: When the battery symbol flashes, the batteries are weak.

If they are not replaced the display will fade. When the
batteries are dead the display will be blank and there will
be no temperature control.

NOTE: If you plan to be away from the premises over 30 days, we

recommend that you replace the old batteries with new alka-
line batteries prior to leaving.

CONFIGURATION

The reset button can be pressed with a paper clip to reset the thermo-
stat back to the factory defaults as shown in the Configuration Menu
Options table.
The Configuration Menu allows you to set certain thermostat operating
characteristics for your system or personal requirements. Set System
switch to

OFF, then simultaneously press the UP and DOWN arrows

for three seconds to enter the Configuration Menu which summarizes
the options available. The display will show the first item in the Con-
figuration Menu Options table. An explanation of each option is listed
after the table. Press the

DOWN arrow to change to the next menu

item. To change the setting, press the

UP arrow. When the maximum

setting is reached, the selections will return to the lowest selection. To
exit the menu and return to the program operation, press the

DOWN

arrow until the main display appears. If no buttons are pressed within
fifteen seconds, the thermostat will revert to normal operation.

COMPRESSOR PROTECTION

The thermostat provides a 4 minute delay after shutting off the
heating or cooling system before it can be restarted. This feature will
prevent damage to your compressor caused by rapid cycling. Note
that this delay also applies to the heating system control. It does not
provide a delay when there are power outages.

TEMPERATURE RANGE

This thermostat can be set between 45ºF and 90ºF (7ºC and 32ºC).
However, it will display room temperatures from 30ºF to 99ºF (0ºC and
37ºC).
NOTE: If the thermostat measures a temperature over 99ºF (37ºC), HI

will be displayed on the LCD. If the temperature is below 32ºF
(0ºC), LO will be displayed on the LCD.

AUTO CUT-OFF

Your thermostat will automatically shut down in Heat mode if the room
temperature rises above 95ºF (35ºC). It will shut down in Cool mode if
the room temperature drops below 45ºF (7ºC).
Note that if your system has malfunctioned and no longer responds to
thermostat controls, the Auto Cut-Off will not work.

EMERGENCY HEAT - RS3210 WITH HEAT PUMP

Consult with your installer to determine if your system is a heat pump
with an emergency heat system installed. If you have an emergency
heat system you can activate it by pressing the

EMER button. The

display will show an

E by the flame icon when the thermostat is in

system

HEAT mode.

The main heating system will not receive a call to turn on. This will
allow maintenance to take place on the main heat system. To turn off
the emergency system, press the

EMER button. The E will no longer

be displayed.

POWER FAILURE

Whenever the main power is interrupted or fails, the back-up battery
power will maintain the current settings. The heating and cooling
systems will not function. In the event of a power outage and dead
batteries, the settings will revert to default settings when power is
resumed. You must reprogram your settings.

FILTER MONITOR

The thermostat counts the number of hours your system’s filter has
been in use. To maximize your system’s performance and energy
efficiency, change or clean your filter regularly. When the total system
run time for heat and cool reaches 400 hours, the filter change
indicator (

Check FLtr) will flash as a reminder to check your system’s

filter. Press and hold the

FILTER button until Check FLtr no longer

displays. This will reset the filter monitor to zero.

DISPLAY MAP

The thermostat display will show information that is being used during
operation or programming. This illustration numbers each display ele-
ment and provides an explanation for each one.

2

4

3

1

5

6

7

8

9

10

HOME

TODAY

Figure 5

1. Event names (used for editing schedule).
2. Day is displayed on Idle screen. Also used to display ranges

when editing the schedule (e.g. SAT SUN for weekend).

3. On when running a schedule.
4. Used with setpoint.
5. Used for service reminders (e.g. CHECK HP).
6. Used for time, current setpoint and some configuration data.
7. HVAC mode and status. Icons blink when active. A is for Auto, 2

is for second stage and

E is for emergency.

8. Indicates when security is active.
9. Low battery indicator.
10. Used for ambient temperature and configuration data (e.g. first

stage differential, F or C, etc.).

+

- +

-

LCD Display

Down and Up

Arrows

Battery

Compartment

Door Latch

System Switch

Fan Switch

HOLD
/RUN

AUTO
PROG

HOME
TODAY

HOUR

MIN

DAY

PROG

FILT

PROG
DAY

EMER

Home Today

Hour

Minutes

Day

Emer

Prog

Hold/Run

Prog Day

Filter

Auto Prog

Reset Button

Figure 4

Home Today - Press to override programmed settings with manual
setting.
LCD Display - Shows Time, Day, Temperature and other feature
information.
Down and Up Arrows - Used to enter and navigate the configuration
menu and change the temperature settings.
Battery Compartment - Open with finger from sides. Install two AA
1.5V batteries.
Filter - Press to reset filter timer to zero.
Door Latch - Press gently on door to open/close.
Reset Button - Press to return to factory default.
Auto Prog - Press to change current program setting to energy sav-
ings setting.
System Switch - Select Cool/Off/Heat/Auto.
Fan Switch - Set for continuous or automatic fan operation.
Prog Day - Press to select between morn, day, eve, nite programs.
Emer - If an emergency heat source is connected, press this button to
activate it.
Hold/Run - Press to hold set temperature until pressed again to run
program.
Prog - Press to enter into programming mode.
Day - Press to change the day.
Minutes - Press to change the minutes.
Hour - Press to change the hour.
IMPORTANT: Please read the entire User Manual

section before setting your thermostat.

USER MANUAL

Thank you for selecting our wall thermostat. Robertshaw

®

products

are manufactured to high quality standards and are designed to
provide years of service.
This section is the User Manual where the thermostat features are
described along with instructions on how to program your RS3110
and RS3210 thermostats. Installation is described in detail in the
Installation Manual section.

FEATURES AND BENEFITS

• 5 - 2 Day Programming

Set the weekly program once with four time and temperature
settings. The four set points are followed for five consecutive days.
On the weekend, four different set points can be set for all day
comfort.

• Multi-Stage 2 Heat/1 Cool - RS3210 only

Operates on both multi-stage gas/electric furnaces and heat
pumps to reduce inventory needed.

• New Improved Display makes viewing and setting the temperature

easier.

• Adjustable Temperature Differential maintains optimal customer

comfort.

• Worry-Free Memory Retention - RS3210 only

Maintains set point and programmed parameters, even during
power outages.

• Filter Monitor provides notice when filters need changing.
• Automatic Compressor Short Cycle Protection reduces wear and

tear of HVAC equipment with this system safeguard.

• Temporary Program Override allows for manual temperature

adjustment.

• O and B Terminals provides greater system flexibility.
• Quick Wire Terminal Block uses sturdy wire clamps for fast and

easy installation - no wrapping around screws.

CHECK THERMOSTAT OPERATION
Fan Operation

If your system does not have a G terminal connection, skip to Heating
System.
1. Turn on power to system.
2. Move Fan switch to

ON position. The blower should begin to

operate.

3. Move Fan switch to

AUTO position. The blower should stop

immediately.

Heating System

1. Move System switch to

HEAT mode. If the heating system has a

standing pilot, be sure to light it.

2. Press the

UP arrow to adjust thermostat setting to 1˚F/1˚C above

room temperature. The heating system should begin to operate.
The display should show the flame icon in motion.

3. For a RS3210 system, adjust temperature setting to 3˚F/3˚C

above room temperature. If your system configuration is set for
auxiliary heat, the auxiliary heat system should begin to operate.
A 2 will appear by the flame icon.

4. Press the

DOWN arrow to adjust the thermostat below room

temperature. The heating system should stop operating.

Cooling System

1. Move System switch to select the

COOL mode.

2. Press the

DOWN arrow to adjust thermostat setting below room

temperature. The blower should come on immediately on high
speed, followed by cold air circulation. The display should show
the snowflake icon pulsing.

3. Press the

UP arrow to adjust the temperature setting above

room temperature. The cooling system should stop operating.

If these tests are not successful, remove the thermostat body and
check for bent pins. Check all wiring connections.
If these tests are successful the thermostat is ready to operate using
the factory defaults. To change the configuration settings, refer to
Configuration in the User Manual section.
Installation of the thermostat is now complete. Remove the protec-
tive mylar over the screen and check that fresh batteries are properly
installed. Close all doors.

INSTALL BATTERIES

The thermostat will operate using 24 VAC or two AA batteries. When
the two AA batteries are installed the thermostat will continue to run if
the 24 VAC fails.
To open the door to the battery compartment, gently pull down on the
sides. Install two AA batteries following the polarity as shown inside
the compartment. Close the door.

+

- +

-

Figure 3

When the batteries are low the thermostat will enter a low battery
mode.
Low battery mode has two levels:

• Level 1 - The low battery icon will be

displayed. The thermostat will continue to
operate. Replace the batteries as soon as
possible.

• Level 2 - The low battery icon will flash. If 24

VAC is present the thermostat will continue
to operate if the batteries are discharged
or removed. If 24 VAC is not present, the
thermostat is powered by batteries only and
THE SYSTEM WILL NOT OPERATE. Replace
batteries immediately.

Replace batteries if leaving thermostat unattended for more than
30 days.

D. Wiring diagram for single transformer heat pump system. System

selector in configuration menu must be set to

HP.

NOTE: “Battery Operation Only” if 24 VAC common not present, other-

wise “Battery Backup”.

C R O B G Y1 E/W1

24 VAC

Common

(Battery

Operation

Only if not

present)

24 VAC

Supply

Fan Relay

Compressor

Contactor

Cool Active

Reversing

Valve

Heat Active

Reversing

Valve

L

W2

Compressor

Fault Output

(24 VAC) from

Heat Pump

Emergency

Heat

Second

Stage or

Auxiliary Heat

E. Typical wiring diagram for single transformer heat pump systems.

24 VAC

Supply

R

Y1

Compressor

Contactor

O

Reversing

Valve

Energized

in Cool

Mode

B

Reversing

Valve

Energized in

Heat, Off,

Emergency

Mode

24 VAC

120

VAC

Neutral

Hot

Transformer (Class II Current Limited)

C

24 VAC

Common

(Battery

Operation

Only if not

present)

System

Monitor

Switch

L

=

Compressor

Fault Output

(24 VAC) from

Heat Pump

Auxiliary

Heat Relay

Emergency

Heat Relay

G

Fan Relay

E/W1 W2

F. Typical wiring diagram for single transformer heat pump only.

R

G

Fan Relay

Y1

O

Reversing

Valve Ener-

gized in Cool

Mode

B

Reversing Valve

Energized in

Heat, Off,

Emergency

Mode

24 VAC

120

VAC

Neutral

Hot

Transformer (Class II Current Limited)

C

Compressor

Contactor

Stage 1

Emergency

Heat

Heat Relay

Stage 2

Compressor

Fault Output

(24 VAC) from

Heat Pump

E/W1 W2 L

B. Typical wiring diagram for single transformer heat pump system.

System selector switch must be set to

HP.

NOTE: “Battery Operation Only” if 24 VAC common not present, other-

wise “Battery Backup”.

C R O B G Y1 W1

24 VAC

Common

(Battery

Operation

Only if not

present)

24 VAC

Supply

Fan Relay

Compressor

Contactor

Cool Active

Reversing

Valve

Heat Active

Reversing

Valve

Two Stage Heat Single Stage Cool: RS3210

C. Wiring diagram for single transformer standard system. System

selector in configuration menu must be set to

STD2 or STD1

(single stage only).

NOTE: “Battery Operation Only” if 24 VAC common not present, other-

wise “Battery Backup”.

C R O B G Y1 E/W1

24 VAC

Common

(Battery

Operation

Only if not

present)

24 VAC

Supply

Fan Relay

Compressor

Contactor

L

W2

First Stage

Heat

Second Stage

Heat (if STD2

selected)

Terminal

Equipment to

Connect

Description

Two Stage Model RS3210C (Additional Terminals)

W2

Second stage heat

connection

Energizes on a call for second stage
heating.

L

24 VAC compressor

fault output

For input of fault signal from a
compressor.

Replace the cover by inserting the bottom tab on the thermostat body
into the slot at the bottom of the wallplate. Move the cover to meet
the top of the wallplate. Press the top of the body to snap it into the
wallplate.
CAUTION: Do not force the thermostat body onto the wallplate. Termi-

nal pins inside the thermostat may become damaged.

WIRING DIAGRAMS
Heat Pump Terminal Outputs

Refer to the equipment manufacturer’s instructions for specific system
wiring information. You can configure the thermostat for use with a
Heat Pump Type 1, single stage compressor system. This thermostat
is designed to operate a single transformer system. If you have a two
transformer system, cut and tape off one transformer. If transformer
safety circuits are in only one of the systems, remove the transformer
of the system with no safety circuits. If required, replace the remain-
ing transformer with a 75 VA Class II transformer. After
disconnecting one transformer, the two commons must be jumpered
together.
Use the terminal output information below to help you wire the ther-
mostat properly for your system.

Single Stage Heat and Cool: RS3110

A. Typical wiring diagram for single transformer standard system.

System selector switch must be set to

STD.

NOTE: “Battery Operation Only” if 24 VAC common not present, other-

wise “Battery Backup”.

C R O B G Y1 W1

24 VAC Common

(Battery Operation

Only if not present)

24 VAC

Supply

Fan Relay

Compressor

Contactor

First Stage

Heat

If you are unsure if the heating/cooling system requires the thermo-
stat to control the fan, contact a qualified heating and air conditioning
service person.
When the thermostat is configured for heat pump, the thermostat will
always power the circulator fan on a call for heat in the Heat mode.
The

ELEC/GAS switch for the 2 stage RS3210 model must be set to

match the type of auxiliary heat your system uses for proper operation
in the Emergency mode.
All wiring diagrams are for typical systems only. Refer to the
equipment manufacturer’s instructions for specific system wiring information.

Thermostat Terminals

Terminal

Equipment to

Connect

Description

One Stage Model RS3110

C

24 VAC common

connection

For input of 24 VAC common side
of transformer.

If 24 VAC is not

present the thermostat is pow-
ered by batteries only and THE
SYSTEM WILL NOT OPERATE.

R

24 VAC + connec-

tion

For input of 24 VAC hot side of
transformer runs heating and cool-
ing system.

O

Energizes for heat pump cool
reversing valve.

B

Energizes for heat pump heat
reversing valve.

G

Indoor fan con-

nection

Energizes with Y1 and Y2.
Energizes with W1 and W2 if the
ELEC/GAS switch is set to electric.
Energizes when fan is switched to
ON.

Y1*

First stage com-

pressor connection

Energizes on a call for first stage of
cooling.
Energizes on a call for first stage of
heating when configured as a

HP.

E/W1*

First stage heat /

emergency heat

connection

Energizes on a call for first stage
of heating when configured as a
Non-Heat Pump. For Heat Pump
configuration, will energize for
emergency heat.

*This thermostat can be used as a heat only or cool only thermostat.
Therefore, it is not always necessary to use both W1 and Y1.

Mounting Holes

Terminals

Figure 1 Thermostat Base

System Switch Selection

STD

HP

Heat Pump or Non-Heat Pump (RS3110 only)

Electric or Gas

GAS

ELEC

Figure 2 Electric/Gas Switch (Fan Option)

The RS3110 thermostat is configured from the factory to operate a
heat/cool, fossil fuel (gas, oil, etc.), forced air system. It is configured
for any system that DOES NOT require the thermostat to energize the
fan on a call for heat.
The RS3210 is configured at the factory to operate an electric heat or
heat-pump system that requires the thermostat to turn on the fan on
a call for heat. Locate the

ELEC/GAS switch on the back of the ther-

mostat (see “Figure 2 Electric/Gas Switch (Fan Option)”) and switch it
to the

ELEC position. This will allow the thermostat to energize the fan

immediately on a call for heat.
Press the reset button to accept a change in the switch option.
If your system is not a heat pump system, refer to the Configuration
section in this manual. The RS3210 thermostat must be changed to a
STD type system.

4. Identify each wire attached to the old thermostat.
5. Label each wire to identify which terminal it was connected to.
6. Disconnect the wires from the old thermostat one at a time. DO

NOT LET WIRES FALL BACK INTO THE WALL.

7. Install new thermostat using the following procedures.
WARNING: Do not use on circuits exceeding specified voltage. Higher

voltage will damage the control and could cause an
electrical shock or fire hazard. Do not short out terminals
on gas valve or primary control to test.
Incorrect wiring will damage the thermostat and could
cause personal injury and/or property damage.

Attach Thermostat Base to Wall

1. Remove the packing material from the thermostat. Push in on

the tab at the bottom. Gently pull the cover straight off the base.
Forcing or prying on the thermostat will cause damage to the
unit.

CAUTION: Be certain all power is off to the system.
2. Pull the wires through the hole in the base. Connect the wires

beneath the terminal screws on the base using the table in the
Terminal Connections section.

3. Place the base over the hole in the wall and mark the mounting

hole locations on the wall using the base as a template.

4. Move the base out of the way. Drill the mounting holes.
5. Fasten the base loosely to the wall, using two mounting screws.

Place a level against the bottom of the base, adjust until level,
and then tighten the screws. Leveling is for appearance only
and will not affect the thermostat operation. If you are using
existing mounting holes or if the holes drilled are too large and
do not allow you to tighten the base snugly, use plastic screw
anchors to secure the subbase.

6. Push the excess wire into wall and plug the hole with a fire

resistant material (such as fiberglass insulation) to prevent
drafts from affecting the thermostat operation.

Recycling Thermostat

This thermostat does not contain mercury. However, if this thermostat
is replacing a thermostat that contains mercury in a sealed tube, do
not place your old thermostat in the garbage. Contact your local waste
management authority for instructions regarding proper disposal of
the thermostat. If you have any questions, call Robertshaw technical
support at 1-800-445-8299.

MOUNTING

What you need:
This thermostat includes two #8 slotted screws and two wall anchors
for mounting. To install your thermostat, you should have the following
tools and materials.

• Slotted Screwdriver(s)

• Small Phillips Screwdriver

• Hammer

• Electric Drill and 3/16" Bit

• Two 1.5V (AA) Alkaline

Batteries (included)

Replacing Existing Thermostat

WARNING:

Electrical Shock Hazard
Turn off power at the main power source by unscrewing
fuse or switching circuit breaker to the

OFF position

before installing, removing or cleaning this thermostat.

IMPORTANT:
• Before removing wires from old thermostat, label each wire with

the terminal designation it was removed from.

• Do not install on voltages greater than 30 VAC.
• Do not install on outside walls or in direct sunlight.
1. Shut off electricity at the main fuse box until installation is

complete. Ensure that electrical power is disconnected.

2. Remove old thermostat: A standard heat/cool thermostat

consists of three basic parts:
a. The cover, which may be either a snap-on or hinge type.
b. The base, which is removed by loosening all screws.
c. The switching subbase, or adapter plate is removed by

unscrewing the mounting screws that hold it on the wall.

3. Remove the front cover of the old thermostat. With wires still

attached, remove wallplate from the wall. If the old thermostat
has a wall mounting plate, remove the thermostat and the wall
mounting plate as an assembly.

IMPORTANT SAFETY INFORMATION

WARNING:

Electrical Shock Hazard
Turn off power at the main power source by unscrewing
the fuse or switching the circuit breaker to the

OFF

position before installing, removing or cleaning this
thermostat.

Fire and Electrical Shock Hazard
This device should be installed by a qualified service
technician with due regard for safety as improper
installation could result in a fire and electrical shock
hazard.

Fire and Electrical Shock Hazard
This is a 24 VAC low-voltage thermostat.
Do not install on voltages higher than 30 VAC.

• Do not switch system to

COOL if the temperature is below 50ºF

(10ºC). This can damage your cooling system and may cause
personal injury.

• Do not short (jumper) across terminals on the gas valve or at the

system control to test installation. This will damage the thermostat
and void the warranty.

• Do not connect ground to any terminal in this unit.
• All wiring must conform to local and national building and

electrical codes and ordinances.

• Use this thermostat only as described in this manual.
CAUTION:
• Read all the information in this manual before installing this

thermostat.

• This thermostat is equipped with automatic compressor protection

to prevent damage due to short cycling or extended power
outages. The short cycle protection provides a 4 minute delay
between heating or cooling cycles to prevent the compressor from
being damaged.

• The batteries must be replaced at least every 18-24 months to

assure proper operation. The thermostat will display a flashing low
battery when it is time to replace the batteries. The manufacturer
recommends inserting fresh batteries before leaving for an
extended period.

352-00021-003 Rev B

Digital Programmable Thermostat

Installation and User Manual
Model: RS3110 and RS3210 Series

INSTALLATION MANUAL

The information supplied here is for the mounting, wiring and switch
set up for the RS3110 and RS3210 thermostats. For programming and
operating functions, refer to the User Manual section.
Thank you for selecting our wall thermostat. Robertshaw

®

products are

manufactured to high quality standards and are designed to provide
years of service.
The RS3110 and RS3210 thermostats work with the following climate
control configurations:
• Heat Pump (No Auxiliary Heat)
• Heat Pump (With Auxiliary/Emergency Heat)
• Standard Heat and Cooling Systems
• One Stage Heat/Cool - RS3110
• Two Stage Heat, One Stage Cool - RS3210
• Standard Heat Only Systems
• Millivolt Heat Only Systems - Floor or Wall Furnaces
• Standard Central Air Conditioning
• Gas or Oil Heat
• Electric Furnace
• Hydronic (Hot Water) Zone Heat-2 Wires
• Not to be Used With Split Transformer Systems
The RS3110 and RS3210 thermostats will NOT work with 3-Wire
Hydronic (Hot Water) Zone Heat 110/220 Volts. This thermostat operates
on 24 VAC power or battery power.

352-00021-003 Rev B

191 E. North Avenue
Carol Stream, Illinois 60188 USA
www.invensyscontrols.com
©2012 Invensys Controls 7/12

This manual is related to the following products:
