AH-99-01.3
M90 Handguns - Parts Identification
4 1 4 1 4 1 4 1 4 1
Accessories: 7969-10 Sealant, Pipe Dope (Loctite ® )
7969-11 Sealant, Low Strength (Loctite ® )
LSCH0009-00 Dielectric Grease, 1 oz.
GC-100-K5 Disposable Gun Covers
High Pressure 74147-00 1/4 NPSM(F)
Disconnects: 20404-00 1/4 NPSM(M)
Item # Item # Item # Item # Item #
MISC. P MISC. P MISC. P MISC. P MISC. PAR AR AR AR ARTS - M90 CLASSIC HANDGUN (77132) TS - M90 CLASSIC HANDGUN (77132) TS - M90 CLASSIC HANDGUN (77132) TS - M90 CLASSIC HANDGUN (77132) TS - M90 CLASSIC HANDGUN (77132)
Part # Part # Part # Part # Part # Description Description Description Description Description
Description Description Description Description Description
RECOMMENDED SP RECOMMENDED SP RECOMMENDED SP RECOMMENDED SP RECOMMENDED SPARE P ARE P ARE P ARE P ARE PAR AR AR AR ARTS - M90 CLASSIC HANDGUN (77132) TS - M90 CLASSIC HANDGUN (77132) TS - M90 CLASSIC HANDGUN (77132) TS - M90 CLASSIC HANDGUN (77132) TS - M90 CLASSIC HANDGUN (77132)
Part Number Part Number Part Number Part Number Part Number
No. of Guns No. of Guns No. of Guns No. of Guns No. of Guns
1-2 3-4 5-6 7-8 1-2 3-4 5-6 7-8 1-2 3-4 5-6 7-8 1-2 3-4 5-6 7-8 1-2 3-4 5-6 7-8
Rebuild Kit 78930-03 1 2 2 3
Valve Screw 75442-00 1 2 3 3
Needle, Valve, Ball 73350-00 1 2 3 3
Jam Nut 73351-00 1 2 3 3
Wrench 19749-00 2 2 4 4
Barrel Nut 75324-00 1 2 2 3 Fits handle with 1-7/8" diameter
threads
Barrel Ring 75327-00 1 2 2 3 Fits handle with 1-7/8" diameter
threads
Trigger Screw 6144-00 2 2 4 4
Air Nozzle 78140-00 1 2 3 4
Fluid Nozzle 77080-xxxx 1 2 3 4 Specify nozzle configuration as per
nozzle selection chart.
Fluid Tube 77096-01 1 2 2 3
High Voltage Cable LREA4003-xx 1 1 2 2 xx must be replaced with desired
length of 36, 50, 75, or 100 feet.
Fluid Line 7994-xx 1 2 3 4 xx must be replaced with desired
length of 36, 50, 75, or 100 feet.
Fluid Filter 7720-xx 1 2 3 4 xx must be replaced with -01 for
.005 spacing or -02 for .009 spacing.
Disposable Gun Cover GC-100-K5 1 2 3 4
Resistor Housing 70397-02 1 2 2 3
Conductive Foam 14061-08 1 2 2 3
Conductive Foam 14061-05 2 4 4 6
Notes Notes Notes Notes Notes
Figure 9: Recommended Spare Parts - M90 Cascade Handgun (77132) Figure 9: Recommended Spare Parts - M90 Cascade Handgun (77132) Figure 9: Recommended Spare Parts - M90 Cascade Handgun (77132) Figure 9: Recommended Spare Parts - M90 Cascade Handgun (77132) Figure 9: Recommended Spare Parts - M90 Cascade Handgun (77132)
Figure 10: Recommended Spare Parts - M90 Cascade Handgun (77132) Figure 10: Recommended Spare Parts - M90 Cascade Handgun (77132) Figure 10: Recommended Spare Parts - M90 Cascade Handgun (77132) Figure 10: Recommended Spare Parts - M90 Cascade Handgun (77132) Figure 10: Recommended Spare Parts - M90 Cascade Handgun (77132)
