Ransburg M90 Handguns 77073, 77132 - Manual (Page 44)

AH-99-01.3
M90 Handguns - Parts Identification
4 0 4 0 4 0 4 0 4 0
* Dash number (-XXXX) indicates fluid nozzle configuration.
See Figure 2 "Nozzle Selection Chart" in the "Service" section for nozzle specifications and order
number identification.
** Dash number (-XX) reads in feet (i.e., -36 = 36 feet). These items are available in standard lengths of
36, 50, 75, and 100 feet. When ordering High Voltage Cable, use footage for -XX.
P P P P PAR AR AR AR ARTS LIST TS LIST TS LIST TS LIST TS LIST BULLET BULLET BULLET BULLET BULLET DEFINITION T DEFINITION T DEFINITION T DEFINITION T DEFINITION TABLE (Figure 8) ABLE (Figure 8) ABLE (Figure 8) ABLE (Figure 8) ABLE (Figure 8)
See "Parts List Bullet Definition Table" on page 40.
53 74189-00 Fitting, Air Line
54** LREA4003-xx High Voltage Cable Assembly (For Standard 9040)
55** 7994-xx Fluid Line Assembly
56** 74187-xx Lightweight Air Line (Standard)
57 14061-08 Conductive Sponge
58 7554-10 O-Ring, Solvent Resistant
59 70397-02 Resistor Housing
60 72209-05 O-Ring, Solvent Resistant (2 Required)
61 7720-01 Filter, Fluid (.005 Spacing) (Standard)
7720-02 Filter, Fluid (.009 Spacing)
62 76104-00 Hose, Whip, High Pressure
63 14061-05 Conductive Sponge (2 Required)
64 71880-06 Nipple, Double Male
65 72468-00 Nozzle Tool (Not Shown)
66 19749-00 Multi-Purpose Wrench (Not Shown)
67 ----------------------------------- ------------------------------------------------------------------------------------------------
68 74133-00 Ball Seat Wrenches (Not Shown)
69 76428-00 Nozzle Wrench (Not Shown)
70 20254-01 Spanner Wrench (Not Shown)
71 78823-00 Nut, Spring Retainer, Trigger Adjustment
72 78824-00 Spring, Compression
Item # Item # Item # Item # Item #
M90 CLASSIC HANDGUN - P M90 CLASSIC HANDGUN - P M90 CLASSIC HANDGUN - P M90 CLASSIC HANDGUN - P M90 CLASSIC HANDGUN - PAR AR AR AR ARTS LIST TS LIST TS LIST TS LIST TS LIST (Figure 6) (Figure 6) (Figure 6) (Figure 6) (Figure 6)
Part # Part # Part # Part # Part # Description Description Description Description Description
