Ransburg M90 Handguns 77073, 77132 - Manual (Page 31)

AH-99-01.3
M90 Handguns - Maintenance
2 7 2 7 2 7 2 7 2 7
Reinstall Reinstall Reinstall Reinstall Reinstall
1. Apply a light coating of dielectric grease
to the (3) o-rings and insert the low volt-
age cable plug assembly into the handle.
(DO NOT push the assembly fully into
the handle).
2. Rotate the plug assembly until the slot in
the aluminum housing is aligned with the
set screw in the handle.
3. Push the low voltage cable plug assem-
bly into the handle until it seats into the
hook/transformer assembly.
4. Tighten the set screw until it seats into
the alignment slot of the low voltage
cable plug assembly.
LOW VOL LOW VOL LOW VOL LOW VOL LOW VOLT T T T TAGE CABLE AGE CABLE AGE CABLE AGE CABLE AGE CABLE
REPLACEMENT REPLACEMENT REPLACEMENT REPLACEMENT REPLACEMENT
Removal Removal Removal Removal Removal
1. Using a wrench, unscrew the low volt-
age cable assembly from the low volt-
age cable plug assembly in the handle.
2. Remove the low voltage cable assembly
from the plug assembly by pulling
straight out.
3. Unscrew the low voltage cable assem-
bly from the control unit.
4. Remove the low voltage cable assembly
from the fluid and air hose bundle.
> Prior to working and/or performing
maintenance on any part of the assembly,
make sure that the control unit, AVIATOR,
or MGS system are turned off (locked and/
or tagged out). Also make sure that all
residual voltage is drained from the system
by grounding the electrode.
W A R N I N G W A R N I N G W A R N I N G W A R N I N G W A R N I N G
!!!!!
Cleaning and Inspection Cleaning and Inspection Cleaning and Inspection Cleaning and Inspection Cleaning and Inspection
1. If prior testing has shown that the low
voltage cable assembly is bad, the
cable assembly must be replaced.
2. If the low voltage cable assembly has
not been tested, it should be tested.
(Refer to “Low Voltage Control Unit Test
Assembly” manual, TE-96-01).
3. The low voltage cable assembly can be
wiped with a suitable solvent. DO NOT
soak or submerge the cable assembly
in solvent.
4. Check the full length of cable for wear or
breaks in the cable sheath. If any are
found, the cable assembly should be re-
placed.
Reinstall Reinstall Reinstall Reinstall Reinstall
1. Connect the low voltage cable assembly
to the low voltage cable plug assembly
of the handle.
> The low voltage cable assembly is not
repairable due to its construction. The
cable assembly must be replaced.
N O T E N O T E N O T E N O T E N O T E
2. Route the low voltage cable assembly
back to the low voltage control unit and
attach the cable assembly into the air
and fluid hose bundle.
3. Connect the low voltage cable assembly
to the low voltage control unit.
> DO NOT DO NOT DO NOT DO NOT DO NOT over tighten the low voltage
cable connection to the handgun as damage
to the plastic parts may occur.
C A U T I O N C A U T I O N C A U T I O N C A U T I O N C A U T I O N
!!!!!
ARCHIVE
