M90 Handguns - Installation
INST INST INST INST INSTALLA ALLA ALLA ALLA ALLATION TION TION TION TION
TYPICAL M90 CASCADE TYPICAL M90 CASCADE TYPICAL M90 CASCADE TYPICAL M90 CASCADE TYPICAL M90 CASCADE
HANDGUN INST HANDGUN INST HANDGUN INST HANDGUN INST HANDGUN INSTALLA ALLA ALLA ALLA ALLATION TION TION TION TION
Connect the low voltage cable to the control unit
low voltage socket. Gently hand tighten the
cable retaining nut. Connect the other end of
the low voltage cable to the handgun, using a
wrench to tighten.
1 0 1 0 1 0 1 0 1 0
> Install and route the hoses and cable
so they are NOT NOT NOT NOT NOT exposed to tempera-
tures in excess of 120 ° F and so that all
hose bends are NOT LESS NOT LESS NOT LESS NOT LESS NOT LESS than a 6
inch (15 cm) radius. Failure to comply
with these guidelines could cause equip-
ment malfunctions that might create
HAZARDOUS CONDITIONS!
HAZARDOUS CONDITIONS! HAZARDOUS CONDITIONS! HAZARDOUS CONDITIONS! HAZARDOUS CONDITIONS!
W A R N I N G W A R N I N G W A R N I N G W A R N I N G W A R N I N G !!!!!
> DO NOT DO NOT DO NOT DO NOT DO NOT overtighten the low voltage
cable connection to the handgun. Dam-
age to plastic parts may occur.
C A U T I O N C A U T I O N C A U T I O N C A U T I O N C A U T I O N !!!!!
> Refer to the control unit service
manual for the circuit diagram and instruc-
tions to connect the control unit.
N O T E N O T E N O T E N O T E N O T E
SAFE INST SAFE INST SAFE INST SAFE INST SAFE INSTALLA ALLA ALLA ALLA ALLATION TION TION TION TION
• Ground the spray booth, the paint supply, and
the conveyor or work support.
• Ground all solvent and waste safety contain-
ers.
• Ground all work holders and hooks and keep
them free of paint.
• Ground the target object to a structural ground
and not back to the applicator system. Ensure
that all target objects have a resistance to
ground of one megohm or LESS.
This information is intended ONLY to indicate
general installation guidelines of this product
and its working relationship to other ITW Rans-
burg system components. Each installation is
unique and should be directed by an ITW
Ransburg representative.
The control unit may be connected through con-
duit with an explosion-proof switch on or near
the spray booth where it will be convenient to
the operator, or may be connected with a power
cord depending upon application requirement.
• Ensure that all elements of the coating system
are correctly grounded, connected, and lo-
cated.
• Position all non-approved electrical apparatus
(including, but not limited to, high voltage
power supplies, fluid pumps, and air compres-
sors) outside of the hazardous location. See
the appropriate NFPA and/or OSHA guidelines
for your application and equipment.
• Provide appropriate fire extinguishing equip-
ment.
• Provide conductive flooring in all spray areas.
• Follow all NFPA guidelines.
> NEVER NEVER NEVER NEVER NEVER wrap the applicator, associated
valves and tubing, and supporting hardware
in plastic to keep it clean. A surface charge
may build up on the plastic surface and
discharge to the nearest grounded object.
Efficiency of the applicator will also be
reduced and damage or failure of the applica-
tor components may occur. WRAPPING
WRAPPING WRAPPING WRAPPING WRAPPING
THE APPLICATOR IN PLASTIC WILL THE APPLICATOR IN PLASTIC WILL THE APPLICATOR IN PLASTIC WILL THE APPLICATOR IN PLASTIC WILL THE APPLICATOR IN PLASTIC WILL
VOID WARRANTY.
VOID WARRANTY. VOID WARRANTY. VOID WARRANTY. VOID WARRANTY.
