Ransburg M90 Handguns 77073, 77132 - Manual (Page 43)

AH-99-01.3
M90 Handguns - Parts Identification
3 9 3 9 3 9 3 9 3 9
(Continued on Next Page) (Continued on Next Page) (Continued on Next Page) (Continued on Next Page) (Continued on Next Page)
See "Parts List Bullet Definition Table" on page 40.
1 77095-00 Nut, Nozzle
2 78140-00 Nozzle, Air
2A LSOR0005-11 O-Ring, Solvent Proof
3* 77080-xxxx Nozzle, Fluid
4 ----------------------------------- ------------------------------------------------------------------------------------------------
5 75442-00 Valve Seat Body Assembly
6 72375-03 Seal
7 73350-00 Needle, Valve, Ball
8 73344-00 Spreader, Seal
9 73345-00 Seal, U-Cup, Front
10 73346-00 Pusher, Seal
11 73352-00 Needle/Shaft Assembly
12 72378-01 Tube, Packing
13 73347-00 Container, Rear Seal
14 74330-00 U-Cup Seal
15 73348-00 Retainer, Rear Seal
16 73354-00 Nut, Packing
17 78822-00 Nut, Trigger Adjusting
18 77133-00 Barrel Assembly
19 75324-00 Nut, Barrel Retainer (For Composite Handle)
20 75327-00 Retaining Ring, Barrel
21 LREM0012-00 Gasket
22 78641-00 Handle (Composite)
23 77093-00 Lever, Blade
24 20099-03 Spring, Wave
25 75389-00 Screw
26 72399-01 Pin, Cylinder
27 18824-00 Hook
28 18871-00 Trigger Assembly (Two Finger)
29 6144-00 Screw, Shoulder (2 Required)
30 78788-00 Needle, Valve
31 18829-00 Spring, Compression
32 18833-00 Washer, Retaining (2 Required)
33 13076-08 O-Ring, Solvent Proof
34 77019-00 Housing
35 77018-00 Screw, Adjusting
36 ----------------------------------- ------------------------------------------------------------------------------------------------
37 ----------------------------------- ------------------------------------------------------------------------------------------------
38 ----------------------------------- ------------------------------------------------------------------------------------------------
39 77015-00 Cap (2 Required)
40 72474-01 Spring, Compression
41 78635-00 Nut, Retaining (Rod Seal)
42 10051-05 Seal, Spring Loaded U-Cup
43 79310-00 Rod Assembly, Air Valve, Dual Stage
44 17130-00 Spring, Compression
45 79317-00 Cap, Air Valve
46 19603-10F Set Screw, Handle
47 72375-02 Seal (Teflon), Fluid Tube
48 77096-01 Tube, Fluid
49 76105-00 Swivel, High Pressure
50 73753-00 Bracket, Line and Cable Assembly
50A 19603-06F Screw Set
51 73351-00 Nut, Jam
52 7554-11 O-Ring, Solvent Resistant (3 Required)
Item # Item # Item # Item # Item #
M90 CLASSIC HANDGUN (77132) - P M90 CLASSIC HANDGUN (77132) - P M90 CLASSIC HANDGUN (77132) - P M90 CLASSIC HANDGUN (77132) - P M90 CLASSIC HANDGUN (77132) - PAR AR AR AR ARTS LIST TS LIST TS LIST TS LIST TS LIST (Figure 8) (Figure 8) (Figure 8) (Figure 8) (Figure 8)
Part # Part # Part # Part # Part # Description Description Description Description Description
