Ransburg EFM & EFMD Solvent Applicator 76480, 76482, 76485, 76488 - Manual (Page 64)

AA-99-01.1 5 9 5 9 5 9 5 9 5 9
EFM(D) Solventborne Robotic Atomizers - Parts Identification
1 76545-00 Applicator Valve Body, Dual, 60 Heads 1
2 EMF-406 Valve Cover Assembly 1
3 EMF-20 Air Fitting 2
4 SSP-6076 Tube Fitting, Nylon, 5/16"T 2
5 75699-01 Tube Fitting, Barb, 1/16" ID Tube 5
6 SSF-3129 Screw, SHCS, 6-32 x 1.00" Long, Steel, Black 3
7 74161-00 Spring, Compression 2
8 74160-00 Needle and Seat Assembly 2
9 76369-00 Retainer, Seat 2
10 76370-00 Support, Lower, Diaphragm, 1.00" 1
11 76371-00 Support, Upper, Diaphragm, 1.00" 1
12 76404-00 Cap, Regulator, 2.00" 1
13 76405-00 Spacer, Diaphragm, Support, 2.00" 1
14 76374-08C Screw, PHMS, #4-40 x .25" Long, Stainless Steel 2
15 76378-00 Diaphragm, 2.00" 1
16 SSG-8172 O-Ring, Solvent Resistant 3
17 76376-00 Regulator Cap, 1.00" 1
18 76375-00 Spacer, Diaphragm, Support, 1.00" 1
19 ---- ---- --
20 7554-09 O-Ring, Fluorocarbon, Viton 2
21 76377-00 Diaphragm, 1.00" 1
22 SSG-8128 O-Ring, Solvent Resistant 1
23 SSP-7816 Nut, Nylon, 3/8"T 2
24 7554-05 O-Ring, Fluorocarbon, Viton 1
25 7554-33 O-Ring, Fluorocarbon, Viton 2
26 LSOR0005-06 O-Ring, Teflon Encapsulated 1
27 SSG-8136 O-Ring, Solvent Resistant 4
28 EMFD-407 High Voltage Extension Assembly 1
29 EMF-413 Air Cartridge Valve Assembly 2
30 EMFD-9 Spring, H.V. Contact 2
31 76407-00 Support, Lower, Diaphragm, 2.00" 1
32 76406-00 Support, Upper, Diaphragm, 2.00" 1
33 SSP-9011 Ferrule, Front, 3/8"T, Nylon 2
34 SSP-9012 Ferrule, Back, 3/8"T, Nylon 2
Item # Item # Item # Item # Item #
76487 76487 76487 76487 76487 V V V V VAL AL AL AL ALVE MANIFOLD ASSEMBL VE MANIFOLD ASSEMBL VE MANIFOLD ASSEMBL VE MANIFOLD ASSEMBL VE MANIFOLD ASSEMBLY Y Y Y Y - P - P - P - P - PAR AR AR AR ARTS LIST TS LIST TS LIST TS LIST TS LIST
(Figures 21a & 21b) (Figures 21a & 21b) (Figures 21a & 21b) (Figures 21a & 21b) (Figures 21a & 21b)
Part # Part # Part # Part # Part # Description Description Description Description Description Qty Qty Qty Qty Qty
