AA-99-01.1 3 3 3 3 3 3 3 3 3 3
EFM(D) Solventborne Robotic Atomizers - Maintenance
9410-01 Plug Nut 9410-01 Plug Nut 9410-01 Plug Nut 9410-01 Plug Nut 9410-01 Plug Nut
The 9410-01, Plug Nut, is used in conjunction with
the dump plugs to keep paint from going out the
dump lines. This plugs the dump port on the
valve manifold.
Misc. Shunts Misc. Shunts Misc. Shunts Misc. Shunts Misc. Shunts
77109-00 Regulator Shunt, EFM
77107-01 Regulator Shunt, EFMD-90°
77107-02 Regulator Shunt, EFMD-60°
These shunts are used to bypass the regulators
in the applicator.
Misc. Dump Plugs Misc. Dump Plugs Misc. Dump Plugs Misc. Dump Plugs Misc. Dump Plugs
EMF-98 Front Plug
EMF-99 Rear Plug
SSG-8161 O-Ring
These dump plugs are used to block the dump
ports in the spray heads when the dump feature
is not desired.
76740 O-Ring Kit 76740 O-Ring Kit 76740 O-Ring Kit 76740 O-Ring Kit 76740 O-Ring Kit
This kit is used to convert the EFM/EFMD appli-
cators to a 100% solvent resistant o-ring appli-
cator.
1 76630-007 O-Ring, Solvent Resistant 2 2
2 SSG-8127 O-Ring, Solvent Resistant 2 3
3 SSG-8163 O-Ring, Solvent Resistant 5 6
4 SSG-8134 O-Ring, Solvent Resistant 6 10
5 SSG-8137 O-Ring, Solvent Resistant 2 2
6 SSG-8136 O-Ring, Solvent Resistant 2 4
7 SSG-8172 O-Ring, Solvent Resistant 1 1
8 SSG-8165 O-Ring, Solvent Resistant 2 2
9 SSG-8149 O-Ring, Solvent Resistant 1 1
10 SSG-8159 O-Ring, Solvent Resistant 2 2
11 SSG-8150 O-Ring, Solvent Resistant 1 1
12 SSG-8151 O-Ring, Solvent Resistant 1 2
13 SSG-8155 O-Ring, Solvent Resistant 1 1
Item # Item # Item # Item # Item #
76740 O-RING KIT 76740 O-RING KIT 76740 O-RING KIT 76740 O-RING KIT 76740 O-RING KIT (Figure 10) (Figure 10) (Figure 10) (Figure 10) (Figure 10)
Part # Part # Part # Part # Part # Description Description Description Description Description
76740-01 76740-01 76740-01 76740-01 76740-01
(Single Head) (Single Head) (Single Head) (Single Head) (Single Head)
Qty Qty Qty Qty Qty
76740-02 76740-02 76740-02 76740-02 76740-02
(Dual Head) (Dual Head) (Dual Head) (Dual Head) (Dual Head)
Qty Qty Qty Qty Qty
