EFM(D) Solventborne Robotic Atomizers - Maintenance

LECU5004 MICROP

LECU5004 MICROPAK

CONTROL UNIT

See

MicroPak Control Unit Service Manual

for service information.

76494-XXX ROBOT

MANIFOLD ASSEMBL

MANIFOLD ASSEMBLY

The 76494-XXX Robot Manifold Assembly is
mounted to the robot wrist and includes two low
voltage power cables and the fluid/pneumatic tubing
required to operate the EFM applicator. This
manifold assembly utilizes swivel fitting fluid and
dump lines that eliminate hose breakage due to
twisting. The fluid and dump lines can quickly be
removed from the manifold by backing out the
radially mounted spring loaded retaining pins.

This manifold assembly is designed to mount
directly to a GMF P150 robot wrist. When mounting
to an ABB robot is desired, an EMFD-54 adaptor
plate is required. This adaptor plate will move the
face of the manifold plate out 1.250 inches from the
robot wrist. EMFD-54-1 (2.250" thick) and EMFD-
54-2 (3.250" thick) adaptor plates are also available
if required.

ACCESSORIES

Accessories for the EFM and EFMD Solventborne
Spray Applicators include:

Misc.

Intrinsic Safe Barrier

75777-XX

Applicator Covers

EMF-430-1

Test Air Cap, with Gauges

EMF-176

Electrode and Air Cap Protectors

76381-XX

Tool Kit

Misc.

Shunts

Misc.

Dump Plugs

9410-01

Plug Nut

76740-XX

O-Ring Kit

76741-00

Barrier, Intrinsic Safe, Dual Channel

76761-01

Ground Bar, Support Bracket

76761-02

Ground Bar, Solid Bus Bar

76761-03

Ground Bar, Clamp Screw

76762-00

Label, Intrinsic Safe Wiring, Blue

76760-00

Rail, DIN Mounting, 35mm

TR-SSEH-382 End Anchor, 35mm DIN

INTRINSIC SAFE BARRIER

INTRINSIC SAFE BARRIER
AND HARDW

AND HARDW

AND HARDWARE

ARE

Part #

Description

75777-01

Single Head Applicator

75777-02

Dual Head Applicator

75777-03

Robot Wrist Flange

75777 APPLICA

75777 APPLICAT

TOR COVERS

OR COVERS

Part #

Description

EMF-430-1 T

EMF-430-1 Test Air Cap

est Air Cap

The EMF-430-1, Test Air Cap, is designed for use
with a Test Station or while the applicator is
connected to the robot or reciprocator. The test air
cap is comprised of two air pressure gauges,
pressure gauge stand, special 76131 air cap, and
all required tubing and fittings.

The air cap has two tapped holes for small barbed
tube fittings. The fittings are located so that the
gauges connected to them will measure the actual
cap pressure of the atomization and pattern air.

Using this test cap will assure uniform atomization
and pattern quality, regardless of air supply tube
lengths from one applicator to another.

EMF-176 Electrode and

EMF-176 Electrode and
Air Cap Protector

Air Cap Protector

The EMF-176 is a plastic cylinder that fits over the
air cap retainer. The protector keeps the electrode
and other spray head parts from being damaged
during booth cleaning and at other times when the
spray applicator is not in use.
